Minimum distance from wall on heater side
During the installation phase observe the minimum dimension
B + 250 as to allow an adequate space for the removal and fitting
of heaters.
Manufacturing and dimensional features
Model with ø 450 mm fan motor
186,5
B
F
A
Model ICE ø 450
Dimensions A
(mm) B
H
Coil inlet
connections (mm)
outlet
Drain connection
GAS
"WD" defrost connection
GAS
Max weight kg
Use thermostatic valve with external pressure equalizer.
Positioning of electric heaters
42A / 43A
06 08 10 12
186,5
H
41B 42A
06 08 10 12 06 08 10 12
1300 2150
880 1730
- -
16 22
35 42
2 2
1 1
1/4 1/4
70 120
41B / 42B / 43B / 44B
06 08 10 12
Minimum distance from wall on suction side
During the installation phase observe the minimum "Y" distance
as to allow proper functioning of motor:
Ø = 450 mm fan motors: Y = 700 mm;
Ø = 560 mm fan motors: Y = 900 mm;
Ø = 560 mm fan motors: Y = 1000 mm.
935
790
100
64
608 184
700 min. 792
42B 43A
06 08 10 12 06 08 10 12
2150 3000
1730 2580
- -
22 28
42 42
2 2
1 1
1/4 1/4
134 169
RBA - High power electric heaters in coil
RBB - Low power electric heaters in coil
RSA - High power electric heaters on drip tray
RSB - Low power electric heaters on drip tray
F
43B 44B
06 08 10 12 06 08 10 12
3000 3850
2580 3430
- 1700
28 28
42 54
2 2
1 2 x 1
1/4 1/4
191 243
3
