5.4 Attaching the CSL Elite Steering Wheel (PS4
version) with
TM
Simplified Quick Release
Use clamp ring screw (M6 x 18mm flat head)
and Allen key from box contents.
Align CSL Elite Wheel Base.
Slide CSL Elite Steering Wheel
onto wheel base axle.
Turn the CSL Elite Steering Wheel top side down to see the bottom side of
the clamp ring to follow next step below.
Push CSL Elite Wheel Base until the screw hole
matches with hole on CSL Elite Racing Wheel axle.
13
