5.4 Attaching a CSL Elite Steering Wheel with simplified Quick
Release
Use clamp ring screw (M6 x 18mm flat head)
and Allen key from box contents.
Align CSL Elite Wheel Base.
Slide Steering Wheel onto wheel
base axle.
Turn the Steering Wheel top side down to see the bottom side of the clamp
ring to follow next step below.
Push the Steering Wheel until the screw hole match-
es with hole on CSL Elite Wheel Base+ axle.
13
