Summary of Contents for FANATEC CSR Elite

  • Page 1 Manual...
  • Page 3 Thank you for choosing Fanatec! To get the most out of and before using your new Forza Motorsport CSR Elite Wheel, please read this manual for important information regarding your health and how to safely use this product. This manual can also be used as a great tool for future reference.
  • Page 4 INDEX 1. General 7. Summary: Modes and button combinations 2. What's in the box 8. Cleaning the wheel 3. Compatibility 9. Troubleshooting 4. Description of buttons and accessories 10. Technical support / FAQ 4.1 Buttons 11. Manufacturer 4.2 Pedals 12. Trademarks 4.3 Additional functions 13.
  • Page 5 Before using this product, read this manual for important safety and health information. Keep all manuals for future reference. For replacement manuals, go to www.fanatec.com WARNING! WARNING! Photosensitive Seizures Musculoskeletal disorders A very small percentage of people may experience a seizure when...
  • Page 6 - If the power cord becomes damaged in any way, stop using it im ing devices must be removed or switched off. mediately and contact Fanatec Customer Support - Not intended for children under the age of 3 years. Support for a replacement.

  • Page 7: What's In The Box

    Your Forza Motorsport CSR Elite Wheel comes with: Microsoft Xbox 360 The Forza Motorsport CSR Elite wheel can be used with all games that • Forza Motorsport CSR Elite Steering Wheel support (Force Feedback) racing wheels. Only newer games (eg. Forza Motorsport 3 and 4) will use extended features like 900°...
  • Page 8 4. Description of buttons and accessories 4.1 XBox 360 button layout BACK START IMPORTANT: This button naming will be used to explain all button combinations...
  • Page 9 4. Description of buttons and accessories 4.2 PlayStation 3 button layout SELECT START...
  • Page 10 4. Description of buttons and accessories 4.3 Additional functions Right Bumper / R1 Tuning button Left Bumper / L1 Power button Xbox 360 Guide button...
  • Page 11 4. Description of buttons and accessories 4.3 Shifter Sequential gear stick (2GS) 6-Speed gear stick + reverse (7GS)
  • Page 12 4. Description of buttons and accessories 4.4 Cables RJ11 to PS/2 Adapter cable Power cable (EU) Power cable (US) XBox 360 Headset adapter cable UK adapter (EU version only) 110V-220V Power supply for wheel...

  • Page 13: Installation

    4 screws to any flat surface. The holes of the pre- mounted adapter are compatible to the CSR and all Porsche wheels of Fanatec. Alternatively you can mount the wheel straight by removing the adapter. Please use the drilling templates in the support section of our website to drill the holes.
  • Page 14 5.2 Table Installation Table installation: To mount the CSR Elite wheel on a table you can use the (optional) Club- Sport Table Clamp (V2). First take off the wheel mounting plate and install it to the wheel. Now attach the wheel with the metal plate to the table clamp...
  • Page 15 5. Installation 5.3 Shifter You do have several options to use the CSR Elite in combination Connect the gear stick to the socket on the backside of your CSR with a Fanatec Shifter: Elite Wheel. Use either the cable which came with your shifters (CSR •...
  • Page 16 Sport Pedals, or G25 / G27 pedals (optional adapter). Connect the pedals with the RJ11 connector to the pedal connector on the backside of the wheel. If you use the ClubSport Pedals or CSR Elite Pedals you can alter- natively connect them directly to the PC as a separate USB controller.
  • Page 17 Turn down the volume by rotating the volume control all the way to the left. Insert the 2.5-mm headset jack into the ffemale connector on the back- side of your CSR Elite wheel. If necessary you can use the supplied mini plug adapter.

  • Page 18: Electrical Connection

    5. Installation 5.6 Electrical connection Please plug-in the power cable of your power supply to the connector on the backside of the wheel. IMPORTANT: Only Use the power supply that came with your CSR Elite wheel.

  • Page 19: Getting Started

    6. Getting started After pressing the power switch it the wheel will self calibrate with a full rotation to the right side and back to the center. Please keep your hands off the wheel during calibration and do not press any pedals. The rim does not have to be perfectly centered after the start sequence.
  • Page 20 After self calibration press the Back Button and hold it for one second. "- - -" will disappear on the display. If you use the wheel for the first time, the CSR Elite must be connected to PC and CSR Elite are connected.
  • Page 21 6. Getting started Tuning button 6.2 Tuning With the tuning feature, you can fine tune your wheel settings independ- ent from the game or platform even during game play directly on the wheel. You can adjust the strength of the Force Feedback and Vibration as well as the best sensitivity for your favourite game.
  • Page 22 6. Getting started 6.2 Tuning Shock Vibration (SHO) To navigate in the tuning menu: 1. Press the Tuning Button The Shock Vibration allows you to adjust the two additional 2. The currently active pre-set will appear, indicated by S_1 vibration motors in the wheel rim that can be controlled by thru S_5.
  • Page 23 6. Getting started 6.3 Calibration 6.2 Tuning [cont.] Wheel Centering Linearity Setting (LIN) 1. Boot the wheel into PC Mode (see page 20) and then turn the rim to its In steps of 10 from 0 to 100% center position. If you like to have the precision around the center of a large 2.

  • Page 24: Fan Control

    6. Getting started 6.3 Calibration 6.4 Fan control A 6-speed gear stick (7GS) must be calibrated when you connect it the first time. The fan is controlled by temperature but for safety reason it is running at maximum speed all the time by default. You can set the fan to be If the shifter is not working properly it might require new calibration as well.
  • Page 25 7. Summary 8. Cleaning Choose platform mode Clean only with a dry or slightly damp cloth. Using cleaning solutions may damage your racing wheel. Power on the wheel and wait until self calibration has finished. Display shows “- - - “. Xbox 360: Press and hold Xbox 360 Guide Button for one second.

  • Page 26: Troubleshooting

    If possible enable telemetry data inside the PCI USB controller card” only for the CSR Elite Wheeel in order to avoid game to check the issue and also connect the wheel to a PC to test its conflichts with other USB.

  • Page 27: Technical Support (Faq)

    10. Technical Support / FAQ 12. Trademarks Technical Support / FAQ: www.Fanatec.com "PlayStation 2", "PlayStation 3" are trademarks of Sony Com- puterEntertainment Inc. "Fanatec" and "Endor" are registered trademarks of Endor® AG/Germany. 11. Manufacturer “Forza Motorsport”, "Microsoft", "Xbox 360", "Xbox Live" ENDOR® AG and "Xbox"...

  • Page 28: Warranty

    10. Warranty Please check the FAQ database at FANATEC.com to see if your This applies in particular to damages with other property, damages problem can be solved there. Normally, the warranty period is two to persons, data losses as well as financial losses like loss of profit years.
