Audio
Realtek ALC888 HD Audio codec onboard
Audio jack supports Line-out and Mic-in
Expansion Slot
1 PCIe(x16) , 1 PCIe x4, 1PCIe (x1) , 4 PCI Slot
(32bit/33MHZ)
Hardware Monitoring
Controller: Winbond W83627DHG
Detection of CPU temperature, System temperature, Power
failure and Fan speed
Watchdog Timer
System reset
Software programmable timer (1-255 level)
Dimensions: 305mm x 244mm (4 layer)
NOTE All specifications and images are subject to change
without notice.
Introduction
IMB202 LGA775 ATX Board User's Manual
3
