Replacement of Foot Ring

1.
Extend chair to the highest seating
position.
2.
Turn chair upside down or on its side.
Hold one of the legs of the five star base
with one hand. Hit the bottom of the
cylinder with a non-marring hammer.
3.
Turn the foot ring as shown and
remove the old foot ring.
4.
Insert the new foot ring as shown and
tighten.
5.
Reinstall chair base.
1
3
2
4
Page 5 of 16
939500070 Rev E
