Campfire
Big Table, Big Table with Trough, Big Table with Power
™
& Half Depth Big Table
©
2017 Steelcase Inc.
Grand Rapids, MI 49501 U.S.A.
Printed in U.S.A.
Big Table
Big Table
Pages 1 - 2
Big Table
with Trough
Pages 3 - 5
Big Table
with Power
CAM LOCK NOTE:
Pages 6 - 7
If cam lock is installed high on the
surface, tap it down flush with the
surface. If that doesn't work,
replace part.
If cam lock is installed low into
the surface, screw cam pin out
to extend the length of the
Half Depth
cam pin.
Big Table
Page 8
1
6x
Cam Lock Fastening
(The cam lock screw needs
to be turned 3/4 full turn
o
or 270
for complete
engagement.)
CAM LOCK
(See cam lock note)
Make sure the cam
lock is located parallel
to the side of the
surface as shown.
Page 1 of 10
939500545 Rev D
R
Advertisement
Related Manuals for Turnstone Campfire
Summary of Contents for Turnstone Campfire
- Page 1 Campfire Big Table, Big Table with Trough, Big Table with Power ™ & Half Depth Big Table Big Table Big Table Pages 1 - 2 Big Table with Trough Pages 3 - 5 Cam Lock Fastening (The cam lock screw needs...
- Page 2 Optional Mobile Cabinet Stop Brackets Apply stickers on all visible cam joint faces to cover the connector faces, after assembly. (LPL and HPL only). Page 2 of 10 939500545 Rev D...
- Page 3 Big Table with Trough Apply stickers on all visible cam joint faces to cover the connector faces, after assembly. Cam Lock Fastening (LPL and HPL only). (The cam lock screw needs to be turned 3/4 full turn or for complete engagement.) Page 3 of 10 939500545 Rev D...
- Page 4 Page 4 of 10 939500545 Rev D...
- Page 5 Page 5 of 10 939500545 Rev D...
- Page 6 Big Table with Power Cam Lock Fastening (The cam lock screw needs to be turned 3/4 full turn or Apply stickers on all for complete engagement.) visible cam joint faces to cover the connector faces, after assembly (LPL and HPL only). Page 6 of 10 Optional Mobile Cabinet 939500545 Rev D...
- Page 7 Page 7 of 10 939500545 Rev D...
- Page 8 Half Depth Big Table Apply stickers on all visible cam joint faces to cover the connector faces, after assembly (LPL and HPL only). Cam Lock Fastening (The cam lock screw needs to be turned 3/4 full turn or for complete engagement.) Page 8 of 10 Optional Mobile Cabinet Stop Brackets...
-
Page 9: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical furnishing, basic precautions should always be followed, including the following: Read all instructions before using the Campfire powered table system. DANGER - To reduce the risk of electric shock: PELIGRO Always unplug this furnishing from the electrical outlet before cleaning. -
Page 10: Operating Instructions
DANGER SAVE THESE INSTRUCTIONS - Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if This appliance is intended for commercial and residential use only. you are in doubt as to whether the product is properly grounded. Do not modify the Connect this appliance to a properly grounded outlet only.
