Jenny
Lounge Chair - Rear Leg Replacement
©
2016 Steelcase Inc.
Grand Rapids, MI 49501 U.S.A.
Printed in U.S.A.

INSTALL NEW STYLE REAR LEGS

1.
Flip chair upside down.
2.
Locate the two holes toward
the back of the chair. Insert the
alignment pin on the leg to the
hole closest to the outside
edge of the chair.
3.
Insert socket head cap
screw into hole on leg and
tighten.
SOCKET HEAD
CAP SCREW
ALIGNMENT PIN
1
3
3
2
SOCKET HEAD
CAP SCREW
HEX DRIVE
2
ALIGNMENT
PIN
Page 1 of 2
1024227001 Rev A
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jenny Lounge Chair and is the answer not in the manual?

Questions and answers

Summary of Contents for Turnstone Jenny Lounge Chair

  • Page 1 Jenny ™ Lounge Chair - Rear Leg Replacement INSTALL NEW STYLE REAR LEGS Flip chair upside down. Locate the two holes toward the back of the chair. Insert the alignment pin on the leg to the hole closest to the outside edge of the chair.
  • Page 2 FLAT HEAD WOOD SCREW REMOVE OLD STYLE REAR LEGS AND INSTALL NEW STYLE REAR LEGS Flip chair upside down. OLD STYLE NEW STYLE REAR LEG REAR LEG Remove the two (2) flat head wood ORDERED PRIOR ORDERED ON OR TO FEB. 15, 2016 AFTER FEB.
