1.5

Serial Label with UDI

The label is located on the case of the SCU (System Control Unit) under the foot section of the bed.
1
4
Fig. Serial Label with UDI (Multicare LE with scales)
4
5
Fig Serial Label with UDI (Symbioso - SCU)
.
1 Address of Distributor
2
Manufacturing Date (Year-Month-Day)
3 DI (Device Identifier) / GTIN (Global Trade Item Number)
4 1D Bar code GS1-128 (Serial Number)
5 Symbols
6 Configuration number
7 Electrical Specification
8 Serial Number
9 PI (Product Identifier)
10 2D Bar Code (GS1 DataMatrix) DI+PI=UDI
5
1
3
2
7
6
3
10
9 8
8 9 10
2
8
