- Page 1 PFI150 FLAT INCLINE BENCH Owner’s Manual WWW.BODYSOLID.COM V PFI150-20200618...
- Page 2 #DWRULE-4 #DWRULE-4...
-
Page 3: Table Of Contents
PFI150 TABLE OF CONTENTS • SAFETY INSTRUCTIONS....... PAGE 4 • PREPARATION........PAGE 5 • PART/HARDWARE LIST......PAGE 6 • HARDWARE ILLUSTRATION....PAGE 7 • ASSEMBLY INSTRUCTIONS....PAGE 12 • EXPLODED VIEW........PAGE 19 • CONTACT PAGE........PAGE 20... -
Page 4: Safety Instructions
PFI150 SAFETY INSTRUCTIONS The PFI150 is designed for your enjoyment. By follow- When using exercise equipment, ing these precautions and using common sense, you you should always take basic will have many safe and pleasurable hours of healthful precautions including the exercise with your Powerline Flat Incline Bench. following: After assembly, you should check all functions to • Read all instructions before using the PFI150. These ensure correct operation. If you experience problems, instructions are written to ensure your safety and to protect the unit. first recheck the assembly instructions to locate any possible errors made during assembly. If you are • Do not remove any safety labels from the unable to correct the problem, call the dealer from machine. • Do not allow children on or near the equipment. whom you purchased the machine or call 1-800-556- 3113 for the dealer nearest you. • Use the equipment only for its intended purpose as described in this guide. Do not use accessory attachments that are not recommended by the Obtaining Service manufacturer. Such attachments might cause serious Please use this Owner’s Manual to make sure that... -
Page 5: Preparation
PFI150 PREPARATION Required tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each step. the PFI150 include but are not limit to: While you may be able to assemble the PFI150 using the • Standard Wrench Set illustrations only, important safety notes and other tips may be included in the text. • Metric Wrench Set Some pieces may have extra holes that you will not use. Use • Adjustable Wrench only those holes indicated in the instructions and illustrations. • Standard / Metric Allen Key Set NOTE: With so many assembled parts, proper alignment and adjustment is critical. While tightening the nuts and bolts, be sure to leave Installation Requirements room for adjustments. Follow these installation requirements when assembling the PFI150: NOTE: The bottles that are marked “Poison” is your touch up paint. Keep away from children. Set up the PFI150 on a solid, flat surface. A smooth, flat surface under the machine helps keep it level. CAUTION: Obtain assistance! If you feel like you can’t assemble the PFI150 by yourself then do Provide ample space around the machine. Open space not attempt to do so as this could result in around the machine allows for easier access. injury. Review the Installation Requirements before proceeding with the following steps. For aesthetic purposes, insert all bolts in the same direction unless specified (in text or illustrations) to do otherwise. -
Page 6: Part/Hardware List
PFI150 PART LIST Part # DESCRIPTION MAIN FRAME REAR STABILIZER SEAT FRAME BACK FRAME SEAT SUPPORT FRAME BACK SUPPORT FRAME M12x130mm HEX HEAD BOLT M12x120mm HEX HEAD BOLT M12x25mm BUTTON HEAD CAP SCREW M10x95mm HEX HEAD BOLT M10x25mm FLAT HEAD PHILLIPS SCREW M8x45mm HEX HEAD BOLT M8X15mm HEX HEAD BOLT M12 WASHER... -
Page 7: Hardware Illustration
PFI150 HARDWARE ILLUSTRATION Part #1 M12x130mm hex head bolt QTY. 1 Part #2 M12x120mm hex head bolt QTY. 1 Part #3 M12X25mm BUTTON HEAD CAP SCREW QTY. 2 PRE-INSTALLED Part #4 M10X95mm HEX HEAD BOLT QTY.2... - Page 8 PFI150 HARDWARE ILLUSTRATION Part #5 M10X25mm FLAT HEAD PHILLIPS SCREW QTY.1 PRE-INSTALLED Part #6 M8X45mm HEX HEAD BOLT QTY. 2 PRE-INSTALLED Part #7 M8X15mm HEX HEAD BOLT QTY. 8 Part #8 M12 WASHER QTY. 6 ...
- Page 9 PFI150 HARDWARE ILLUSTRATION Part #9 M12 LOCK WASHER QTY. 2 Part #10 M10 WASHER QTY. 4 Part #11 M8 WASHER QTY. 12 Part #12 M8 LOCK WASHER QTY. 8 ...
- Page 10 PFI150 HARDWARE ILLUSTRATION Part #13 M12 NYLON LOCK NUT QTY. 2 Part #14 M10 NYLON LOCK NUT QTY. 2 Part #15 M10 NYLON LOCK NUT QTY.
- Page 11 PFI150 NOTE...
-
Page 12: Assembly Instructions
PFI150 STEP 1 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware FIRST. wrench tighten all hardware at the END of step 1A. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. attach Rear Stabilizer (B) to Main Frame (A) using: 2 - (#4) m10x95mm hex head bolt... - Page 13 PFI150 STEP 1 above shows step 1 assembled and completed...
- Page 14 PFI150 STEP 2 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware FIRST. wrench tighten all hardware at the END of step 2B. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. attach Seat Support Frame (E) to Seat Frame (C) using: 1 - (#1) m12x130mm hex head bolt...
- Page 15 PFI150 STEP 2 above shows step 2 assembled and completed...
- Page 16 PFI150 STEP 3 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware FIRST. wrench tighten all hardware at the END of step 3B. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. attach Seat Pad (#18) to Seat Frame (C) using: 4 - (#7) m8x15mm hex head bolt...
- Page 17 PFI150 STEP 3 above shows step 3 assembled and completed...
- Page 18 PFI150 NOTE...
-
Page 19: Exploded View
PFI150 EXPLODED VIEW... -
Page 20: Contact Page
PFI150 please write your serial number in the boxes below 015784-��-��-����-���� S/N # 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST...
