- Page 1 PPR1000 POWER RACK Owner’s Manual WWW.BODYSOLID.COM V PPR1000-092018...
- Page 2 Do not allow the machine to be used until damaged or worn cables are replaced. Using or allowing a machine to be used with a suspect cable can result in serious injury. See Owner’s Manual for more information. For Body-Solid Customer Service Call 1-800-556-3113...
-
Page 3: Table Of Contents
PPR1000 TABLE OF CONTENTS • SAFETY INSTRUCTIONS....... PAGE 4 • PREPARATION........PAGE 5 • PART/HARDWARE LIST......PAGE 6 • HARDWARE ILLUSTRATION....PAGE 7 • ASSEMBLY INSTRUCTIONS....PAGE 8 • EXPLODED VIEW........PAGE 17 • CONTACT PAGE........PAGE 18... -
Page 4: Safety Instructions
Use care when getting on or off the unit. servicing this machine. Failure to do so will void your warranty and could result in personal injury. • Do no overexert yourself or work to exhaustion. • If you feel any pain or abnormal symptoms, stop your workout immediately and consult your physician. For information about product operation or • Never operate unit when it has been dropped or service, check out the official Powerline website at www.bodysolid.com or contact an authorized damaged. Return the equipment to a service center for examination and repair. Powerline dealer or a Powerline factory-authorized • Never drop or insert objects into any opening in the service company or contact Body-Solid customer service at one of the following: equipment. • Always check the unit and its cables before each use. Make sure that all fasteners and cables are secure Toll Free: 1-800-556-3113 Phone: 1-708-427-3555 and in good working condition. Fax: 1-708-427-3556 • Do not use the equipment outdoors or near water. Email: service@bodysolid.com Personal Safety During Assembly Or write to: Body-Solid, Inc. •... -
Page 5: Preparation
PPR1000 PREPARATION Required tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each step. the PPR1000 include but are not limit to: While you may be able to assemble the PPR1000 using the • Standard Wrench Set illustrations only, important safety notes and other tips may be included in the text. • Metric Wrench Set Some pieces may have extra holes that you will not use. Use • Adjustable Wrench only those holes indicated in the instructions and illustrations. • Standard / Metric Allen Key Set NOTE: With so many assembled parts, proper alignment and adjustment is critical. While tightening the nuts and bolts, be sure to leave Installation Requirements room for adjustments. Follow these installation requirements when assembling the PPR1000: NOTE: The bottles that are marked “Poison” is your touch up paint. Keep away from children. Set up the PPR1000 on a solid, flat surface. A smooth, flat surface under the machine helps keep it level. CAUTION: Obtain assistance! If you feel like you can’t assemble the PPR1000 by yourself then do Provide ample space around the machine. Open space not attempt to do so as this could result in around the machine allows for easier access. injury. Review the Installation Requirements before proceeding with the following steps. For aesthetic purposes, insert all bolts in the same direction unless specified (in text or illustrations) to do otherwise. -
Page 6: Part/Hardware List
PPR1000 PART LIST Part # DESCRIPTION BASE FRAME UPRIGHT STEEL BRACKET FOOT PLATE CHIN UP BAR REAR CROSSBAR SIDE CROSSBAR SHORT STEEL BRACKET LONG STEEL BRACKET RIGHT J CUP LEFT J CUP PIPE M12x80mm HEX HEAD BOLT M5X10mm FLAT HEAD CAP SCREW M12 WASHER M12 NYLON LOCKNUT END CAP... -
Page 7: Hardware Illustration
PPR1000 HARDWARE ILLUSTRATION Part #1 M12x80mm hex head bolt QTY . 32 Part #2 M5X10mm FLAT HEAD CAP SCREW QTY. 8 Part #3 M12 WASHER QTY. 64 Part #4 M12 NYLON LOCKNUT QTY. 32 ... -
Page 8: Assembly Instructions
PPR1000 STEP 1 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 1A. - Page 9 PPR1000 STEP 1 above shows step 1 assembled and completed...
- Page 10 PPR1000 STEP 2 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 2A.
- Page 11 PPR1000 STEP 2 above shows step 2 assembled and completed...
- Page 12 PPR1000 STEP 3 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware FIRST in this step. wrench tighten all hardware at the END of step 3A. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten.
- Page 13 PPR1000 STEP 3 above shows step 3 assembled and completed...
- Page 14 PPR1000 STEP 4 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. Adjustable J Cups and Pipe & Pin Safeties 4A.
- Page 15 PPR1000 STEP 4 above shows step 4 assembled and completed...
- Page 16 PPR1000 NOTE...
-
Page 17: Exploded View
PPR1000 EXPLODED VIEW... -
Page 18: Contact Page
PPR1000 please write your serial number in the boxes below 014725-��-��-����-���� S/N # 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST...
