Instructions for use
SMARTair/plus FLEXspace Typ 5230/5231
Always be on the safe side.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMARTair FLEXspace and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KaVo SMARTair FLEXspace

  • Page 1 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 Always be on the safe side.
  • Page 2 Manufacturer: Sales: Kaltenbach & Voigt GmbH KaVo Dental GmbH Bismarckring 39 Bismarckring 39 D-88400 Biberach D-88400 Biberach www.kavo.com Tel. +49 7351 56-0 Fax +49 7351 56-1488...
  • Page 3: Table Of Contents

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 Table of contents Table of contents User instructions ............................3 User guide ............................3 1.1.1 Symbols ..........................3 1.1.2 Target group ........................3 Service ............................3 Warranty terms and conditions ......................3 Transportation and storage ......................4 1.4.1 Currently valid packaging regulations ................
  • Page 4 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 Table of contents 7.2.2 Changing the adsorption filter ..................32 7.2.3 Changing the ultrafine filter ..................... 33 Safety checks ............................37 Troubleshooting ............................38 10 Accessories ............................. 39 11 Spare parts .............................. 40 12 Declaration of conformity .........................
  • Page 5: User Instructions

    12 months from the date of purchase as confirmed by the salesperson. In case of justified complaints, KaVo will honour its warranty with a free replace‐ ment or repair.
  • Page 6: Transportation And Storage

    Properly dispose of and recycle the sales packaging according the applicable packaging ordinance through waste management businesses or recycling compa‐ nies within a comprehensive return system. KaVo has licensed its sales packag‐ ing in accordance with this directive. Please follow the regional public waste dis‐...
  • Page 7: Information On The Packaging: Storage And Transportation

    1 User instructions | 1.4 Transportation and storage Outside Germany Note KaVo is not liable for damage arising from transportation. Immediately inspect the delivery after receipt! If the packaging is visibly damaged on delivery, please proceed as follows: 1. The recipient of the package must record the loss or damage on the delivery receipt.
  • Page 8 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 1 User instructions | 1.4 Transportation and storage Humidity Air pressure 6/42...
  • Page 9: Safety

    2.2 Purpose – Proper use 2.2.1 General The overarching guidelines and/or national laws, national regulations and the rules of technology applicable to machines for the startup and use of the KaVo product for the intended purpose are to be applied and complied with. 7/42...
  • Page 10: Product-Specific

    2.2.2 Product-specific The KaVo product is for vacuuming and separating hazardous dust (with MAK values) and inert dusts and vapours (primarily methyl methacrylate). The use of this KaVo product is not permitted in areas subject to an explosion hazard. Note The KaVo product is not suitable for vacuuming collected dust (such as on the floor).
  • Page 11: Safety Instructions

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 2 Safety | 2.3 Safety instructions 2.3 Safety instructions 2.3.1 General WARNING Injury or damage from damaged functional parts. If functional parts are damaged, it can cause additional damage or personal in‐ jury. ▶...
  • Page 12: Product Description

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 3 Product description | 3.1 Scope of delivery 3 Product description 3.1 Scope of delivery ① Motor filter drawer ⑥ Ultrafine filter (only SMARTair plus FLEXspace)Mat. no. 0.658.9802 ② Extraction hose ⑦ Fan box seat ③...
  • Page 13: Device Parts

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 3 Product description | 3.2 Device parts 3.2 Device parts ① Cover ⑥ Filter flap ② Filter port ⑦ Grip bar ③ Mains switch ⑧ Membrane keypad ④ Voltage selector switch ⑨ Intake opening ⑤...
  • Page 14: Filter Box

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 3 Product description | 3.3 Filter box 3.3 Filter box ① Filter bag ⑤ Fan box ② Fan box flap ⑥ Muffler element ③ Filter flap ⑦ Adsorption filter (optional) ④ Filter box snaplocks ⑧...
  • Page 15: Connections

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 3 Product description | 3.4 Connections 3.4 Connections ① Socket for power cable connector ⑦ Sub-D bus for connection to control panel ② Fuse for line input (10 A) ⑧ Power cable (country-specific) ③...
  • Page 16: Control Panel

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 3 Product description | 3.5 Control panel 3.5 Control panel ① LED automatic mode (green) ⑤ "Automatic" key ② LED continuous operation (green) ⑥ "Minus" key (reduction of the extrac‐ tion level) ③ LEDs suction level display (green) ⑦...
  • Page 17 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 3 Product description | 3.6 Technical Specification Height 430 mm Weight Approx. 13 kg Dimensions and weight of filter drawer Length 450 mm Width 375 mm Height 60 mm Weight Approx. 5 kg Dimensions and weight of fan box seat Length 190 mm...
  • Page 18: Identification Plates

    Storage and transportation conditions Ambient temperature -20 to +55°C Relative humidity 5% to 95% non-condensing Air pressure 700 to 1600 hPa 3.7 Identification plates SMARTair FLEXspace SMARTair plus FLEXspace Type Device type Year of manufacture - serial number Material number CE mark 16/42...
  • Page 19: Dust Test

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 3 Product description | 3.8 Dust test VDE mark CSA mark Disposal instructions, proper use GS mark Follow the Instructions for use 3.8 Dust test GS/BG certificate no.: 0605011 17/42...
  • Page 20: Assembly

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 4 Assembly | 4.1 Location 4 Assembly 4.1 Location The FLEXspace SMARTair (plus) vacuum is designed for installation in the FLEX‐ space workspace. 4.2 Assembly Note Repairs and service tasks may only be performed by qualified professionals ex‐ cept for the activities described in these instructions for use.
  • Page 21 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 4 Assembly | 4.2 Assembly Insert filter drawer ▶ Run the connection line ② and suction hose ① and guide it through the hous‐ ing to the rear. ▶ Insert the filter drawer SMARTair (plus) FLEXspace in the guide and shove it ▶...
  • Page 22 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 4 Assembly | 4.2 Assembly ▶ Place the fan box ② on the floor. ▶ Attach the extraction hose ①. ▶ Plug in the power line ⑤ and ⑥ and Sub-D plug ④. ▶...
  • Page 23 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 4 Assembly | 4.2 Assembly Left installation Note To allow the filter drawer to be removed and inserted when changing the filter, the installation instructions must be precisely followed. ▶ Insert the ② suction hose curved. ▶...
  • Page 24 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 4 Assembly | 4.2 Assembly Right installation ▶ Remove the rails ④. ▶ Rotate the fan box 180°. ▶ Reinstall the rails ④. ▶ Fasten the suction hose at the provided position with a strap ② through the opening ①...
  • Page 25: First Use

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 5 First use | 5.1 Check the filter bag 5 First use ▶ Check that the rated voltage and rated frequency match the rating plate. ▶ Check if the voltage selection switch is set to the national voltage. ▶...
  • Page 26: Operation

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 6 Operation | 6.1 Automatically operate the SMARTair (plus) FLEXspace 6 Operation 6.1 Automatically operate the SMARTair (plus) FLEXspace Note Automatic mode is recommended for units that have an electrical connection. Set the SMARTair (plus) FLEXspace plus to automatic ▶...
  • Page 27: Manually Operate The Smartair (Plus) Flexspace

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 6 Operation | 6.2 Manually operate the SMARTair (plus) FLEXspace 6.2 Manually operate the SMARTair (plus) FLEXspace Note Units without an electrical connection (such as turbine systems) must be operat‐ ed manually. Set up the SMARTair (plus) FLEXspace for manual operation ▶...
  • Page 28: Operate The Smartair (Plus) Flexspace With The Foot Switch

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 6 Operation | 6.4 Operate the SMARTair (plus) FLEXspace with the foot switch Note When the suction decreases from soiling or a full filter, the suction automatically switches to the set suction. Only when the suction limit is reached does the "Fil‐ ter full"...
  • Page 29: Adjust The Suction Levels

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 6 Operation | 6.5 Adjust the suction levels 6.5 Adjust the suction levels ▶ Press the keys ⑥ and ⑦ to adjust the suction levels 1 to 4 (① to ④). 6.5.1 Save the default suction level (as of software version 2) Note As of software version 2.0, the suction level can be saved and is retained after the SMARTair (plus) FLEXspace is turned off.
  • Page 30: Setting The Response Sensitivity

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 6 Operation | 6.6 Setting the response sensitivity You can now save the suction level. ▶ Turn off the power switch ⑤, and turn it on after two seconds. The selected suction level is saved. Deactivate the default suction level ▶...
  • Page 31 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 6 Operation | 6.6 Setting the response sensitivity Setting and saving the response sensitivity ▶ Turn on the power switch on the control unit. ▶ Start the working device at a speed of 5,000 to 7,000 rpm and keep it running while performing the setting.
  • Page 32: Cleaning And Servicing

    7 Cleaning and servicing | 7.1 Cleaning 7 Cleaning and servicing To guarantee constant readiness for use and maintenance of value of the KaVo product, the recommended servicing must be done. This device contains harmful dust. Only professionals and wearing the appropri‐...
  • Page 33: Change The Filter Bag

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 7 Cleaning and servicing | 7.2 Maintenance 7.2.1 Change the filter bag Note To keep the fan motor from being damaged, the filter chamber must be checked for dust and cleaned if necessary before inserting a new filter bag. Note When changing the filter bag, adsorption filter, ultrafine filter and cleaning the fil‐...
  • Page 34: Changing The Adsorption Filter

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 7 Cleaning and servicing | 7.2 Maintenance Exchanging the filter bag ▶ Carefully remove the filter bag from the filter connector ①. ▶ Seal the filled filter bag with the adhesive tab ② and throw it away ③. ▶...
  • Page 35: Changing The Ultrafine Filter

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 7 Cleaning and servicing | 7.2 Maintenance ▶ Switch the power switch ① to "Off". ▶ Pull out the front door of the fan box ②. Exchanging the adsorption filter ▶ Undo the snap locks ②, and open the filter flap ①. ▶...
  • Page 36 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 7 Cleaning and servicing | 7.2 Maintenance Prepare the unit ▶ Switch the power switch ① to "Off". ▶ Pull open the front door ②. Remove the muffler element/adsorption filter ▶ Undo the snap locks ④, and open the filter flap ②. ▶...
  • Page 37 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 7 Cleaning and servicing | 7.2 Maintenance Remove the old ultrafine filter ▶ Loosen and fold back the two clamping strips ① on the ultrafine filter ②. ▶ If possible, bring the house into the open. ▶...
  • Page 38 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 7 Cleaning and servicing | 7.2 Maintenance Reinstall the muffler element/adsorption filter ▶ Insert the muffler element ③ and adsorption filter ①. ▶ Close the filter flap ②. Make sure that the snap locks ④ lock in place. Close the fan box ▶...
  • Page 39: Safety Checks

    Trade Supervisory Office in Celle, the test can be performed by a dental techni‐ cian who has been trained how to use equipment in his journeyman training. Note KaVo recommends checking function annually and observing the sections "Cleaning and servicing" and "Troubleshooting" in these instructions for use. Annual tests ▶...
  • Page 40: Troubleshooting

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 9 Troubleshooting 9 Troubleshooting DANGER Electrical power. Risk of fatal injury. ▶ Have the electrical part of the device repaired and serviced only by profes‐ sionals or persons trained at the factory who have been advised of the safety instructions.
  • Page 41: Accessories

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 10 Accessories 10 Accessories Presentation Brief description Mat. No. Foot switch (Mat. no. 1.000.3147) Connection line for K-Control (Mat. no. 1.000.7198) Adsorption filter (Mat. no. 0.658.1861) Changing the ultrafine filter (Mat. no. 0.658.9802) (on‐ ly the SMARTair plus FLEXspace) Filter bag, package with 5 units for all dust extraction systems (Mat.
  • Page 42: Spare Parts

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 11 Spare parts 11 Spare parts 1.001.2459 1.001.2453 1.001.8264 plus 1.001.8263 0.695.1402 0.251.4546 (M4x10) 1.001.3499 0.266.4086 10 A 1.002.6077 1.001.7126 0.223.2232 1.001.7714 1.001.2457 1.001.2458 0.223.1046 0.223.2741 3,15 A 0.223.2735 4 A 1.001.9102 1.001.6457 1.004.8113 1.001.7712 1 0 0...
  • Page 43 Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 11 Spare parts 1.000.7198 1.001.8191 0.658.1861 1.000.3147 0.658.9802 0.222.6090 0.658.2160 (5 Stk.) 0.220.1455 0.260.9570 0.221.4548 1.002.2685 0.228.3076 (50 Stk.) mtr. 0.065.7552 0.695.1402 2x 0.224.6596 0.659.7392 0.224.6689 ¿ 42 1,2 m ¿ 48/42 1.002.1220 DE 1.002.2525 GB 1.002.2529 CH 1.002.2527...
  • Page 44: Declaration Of Conformity

    Instructions for use SMARTair/plus FLEXspace Typ 5230/5231 12 Declaration of conformity 12 Declaration of conformity 42/42...

This manual is also suitable for:

Smartair plus flexspace
