  • Page 1 Instructions for use SMARTair plus, SMARTair plus mobile Always be on the safe side.
  • Page 2 Distributed by: Manufacturer: KaVo Dental GmbH Kaltenbach & Voigt GmbH Bismarckring 39 Bismarckring 39 D-88400 Biberach D-88400 Biberach Phone +49 7351 56-0 www.kavo.com Fax +49 7351 56-1488...

  • Page 3: Table Of Contents

    Automatically operate the SMARTair plus / SMARTair plus mobile ..........31 Manually operate the SMARTair plus / SMARTair plus mobile ............ 32 Operate the SMARTair plus / SMARTair plus mobile with the foot switch ........33 Adjust the suction levels ........................ 34 6.4.1...
  • Page 4 Servicing ............................37 7.2.1 Exchange the filter bag of the SMARTair plus ..............37 7.2.2 Exchange the filter bag of the SMARTair plus mobile ............38 7.2.3 Changing the adsorption filter of the SMARTair plus ............39 7.2.4 Changing the adsorption filter of the SMARTair plus mobile ..........41 7.2.5...

  • Page 5: User Instructions

    12 months from the date of purchase as confirmed by the salesperson. In case of justified complaints, KaVo will honour its warranty with a free replacement or repair.

  • Page 6: Transportation And Storage

    Properly dispose of and recycle the sales packaging, in accordance with the relevant packaging regulations, through waste management businesses or recycling com‐ panies that run a comprehensive return system. KaVo has licensed its sales pack‐ aging in accordance with this directive. Please conform with the regional, public waste-disposal system regulations.

  • Page 7: Information On The Packaging: Storage And Transportation

    Instructions for use SMARTair plus, SMARTair plus mobile 1 User instructions | 1.4 Transportation and storage If the packaging is visibly damaged on delivery, please proceed as follows: 1. The recipient of the package must record the loss or damage on the delivery receipt.

  • Page 8: Safety

    2.2.1 General information The overarching guidelines and/or national laws, national regulations and the rules of technology applicable to machines for the startup and use of the KaVo product for the intended purpose are to be applied and complied with. This KaVo product has been designed solely for dental technology, industrial and trade applications.

  • Page 9: Product-Specific

    The KaVo product is for vacuuming and separating hazardous dust (with MAK val‐ ues) and inert dusts and vapours (primarily methyl methacrylate). The use of this KaVo product is not permitted in areas subject to an explosion haz‐ ard. Note The KaVo product is not suitable for vacuuming collected dust (such as on the floor).

  • Page 10: Safety Instructions

    Instructions for use SMARTair plus, SMARTair plus mobile 2 Safety | 2.3 Safety instructions 2.3 Safety instructions 2.3.1 General information WARNING Injury or damage from damaged functional parts. If functional parts are damaged, it can cause additional damage or personal injury.

  • Page 11: Disposal Of Electronic And Electrical Devices

    Europe. Before disassembly / disposal, the product must be completely reprocessed (dis‐ infected, sterilised) according to the chapter on "Reprocessing methods". For more information, please contact KaVo (www.kavo.com) or your dental sup‐ plier. For final disposal, contact: Germany To return an electrical device, proceed as follows: 1.

  • Page 12: Product Description

    Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.1 Scope of delivery 3 Product description 3.1 Scope of delivery SMARTair plus ① Motor filter drawer ④ Replacement filter bag ② Power cable ⑤ Instructions for ENMat. no. 1.001.8593 useMat.
  • Page 13 Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.1 Scope of delivery SMARTair plus mobile ① Motor filter box ④ Connection line ENMat. no. 1.002.2525 GBMat. no. 1.002.2529 CHMat. no. 1.002.2527 USMat. no. 1.002.2528 OFFMat. no. 1.002.2530 ②...

  • Page 14: Device Parts

    Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.2 Device parts 3.2 Device parts SMARTair plus device parts ① Cover ⑦ Grip bar ② Rating plate ⑧ Intake opening ③ Connections ⑨ Control panelControl panel ④ Power switch ⑩...

  • Page 15: Filter Box

    Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.3 Filter box 3.3 Filter box SMARTair plus filter box ① Filter bag ⑤ Fan box ② Fan box flap ⑥ Muffler element ③ Filter flap ⑦ Adsorption filter (optional) ④...
  • Page 16 Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.3 Filter box SMARTair plus mobile filter box ① Filter bag ⑤ Fan box ② Fan box flap ⑥ Muffler element ③ Filter flap for SMARTair mobile ⑦ Adsorption filter (optional) ④...

  • Page 17: Connections

    Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.4 Connections 3.4 Connections SMARTair plus connectors ① Socket for power cable connector ⑦ Sub-D socket for connection to mem‐ brane keyboard ② Fuse for line input (10 A) ⑧...
  • Page 18 Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.4 Connections SMARTair plus mobile connectors ① Socket for power cable connector ⑦ Sub-D socket for connection to mem‐ brane keyboard ② Fuse for line input (10 A) ⑧...

  • Page 19: Control Panel

    Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.5 Control panel 3.5 Control panel ① LED automatic mode (green) ⑤ "Automatic" key ② LED continuous operation (green) ⑥ "Minus" key (reduction of the extrac‐ tion level) ③...
  • Page 20 Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.6 Technical data Dimensions and weight of the SMARTair plus Width 450 mm Depth 510 mm Height 540 mm Weight Approx. 17.5 kg Housing Degree of soiling Class of protection...

  • Page 21: Technical Data For The Smartair Plus Mobile

    Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.6 Technical data Permissible mains voltage fluctuation max. ± 10 % of the nominal voltage Permissible in enclosed rooms Storage and transportation conditions Ambient temperature -20 to +55°C...
  • Page 22 Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.6 Technical data Electrical system Nominal voltage 100 / 115 / 230 V Nominal frequency 50/60 Hz Permissible leakage current max. 0.5 mA Mains input fuse 100 to 230 V T 10 A (H) / 250 V...

  • Page 23: Identification Plates

    Instructions for use SMARTair plus, SMARTair plus mobile 3 Product description | 3.7 Identification plates 3.7 Identification plates SMARTair plus SMARTair plus mobile Type Device type Year of manufacture - serial number Material number CE mark VDE mark CSA mark...

  • Page 24: Assembly

    Without any special ventilation measures: L = 1h The SMARTair plus vacuum ② is designed for installation in EWL frames ① or an EWL system base 5. The SMARTair plus mobile vacuum can be set up either standing or lying.

  • Page 25: Installing The Smartair Plus

    ▶ Screw the motor housing ③ and flange ① together with four screws ②. ▶ Insert the Sub-D connector ⑤ into the provided socket in the housing, and affix it with two screws ④. Insert the SMARTair plus into the frame ▶ Remove the cover ② of the SMARTair plus. 23/57...
  • Page 26 Tair plus, and insert it into the provided, easily reachable, properly installed (grounded) power socket. If needed, use an extension cord. ▶ Run the power cable ⑤ so that the SMARTair plus can be pulled out to the stop without unplugging the power cable.
  • Page 27 Instructions for use SMARTair plus, SMARTair plus mobile 4 Assembly | 4.2 Installing the SMARTair plus ▶ Insert the SMARTair plus all the way into the frame 1. Connecting the SMARTair plus to the unit Note When using the control cable (Mat.

  • Page 28: Installing The Smartair Plus Mobile

    Instructions for use SMARTair plus, SMARTair plus mobile 4 Assembly | 4.3 Installing the SMARTair plus mobile Affix the extraction hood ▶ Insert the extraction hood ② into the intake opening ① so that the intake opening is completely covered by the rubber lip.
  • Page 29 ▶ The nominal voltage and frequency must be the same as that on the rating plate. ▶ Set up the SMARTair plus mobile at the provided location. ▶ Switch the power switch ① to "Off". ▶ Insert the provided power cable 2 into the provided connection 3 of the SMAR‐...
  • Page 30 ▶ Connect units (such as the K-Control) with a control output (3.5 mm socket) via a control cable () 2 to the SMARTair plus mobile. Affix the extraction hood ▶ Place the connecting hose ① on the intake connection ② of the SMARTair plus mobile. ▶ Connect the hose to the extraction hood.

  • Page 31: First Use

    Note Do not damage the filter bag. ▶ Pull out the SMARTair plus from the frame ① until the stop , and remove the cover ②. ▶ Check to see if the filter bag ③ is firmly seated.
  • Page 32 Instructions for use SMARTair plus, SMARTair plus mobile 5 First use | 5.2 Check the filter bag of the SMARTair plus Note Do not damage the filter bag. ▶ Undo the snap locks, and slightly pull apart the grip bars ①.

  • Page 33: Operation

    Instructions for use SMARTair plus, SMARTair plus mobile 6 Operation | 6.1 Automatically operate the SMARTair plus / SMARTair plus mobile 6 Operation Note The distance between the item generating the dust (such as a cutter) and the intake opening may not exceed 50 mm.

  • Page 34: Manually Operate The Smartair Plus / Smartair Plus Mobile

    Instructions for use SMARTair plus, SMARTair plus mobile 6 Operation | 6.2 Manually operate the SMARTair plus / SMARTair plus mobile 6.2 Manually operate the SMARTair plus / SMARTair plus mobile Note Units without an electrical connection (such as turbine systems) must be operated manually.

  • Page 35: Operate The Smartair Plus / Smartair Plus Mobile With The Foot Switch

    Instructions for use SMARTair plus, SMARTair plus mobile 6 Operation | 6.3 Operate the SMARTair plus / SMARTair plus mobile with the foot switch Note When the suction decreases from soiling or a full filter, the suction automatically switches to the set suction. Only when the suction limit is reached does the "Filter full"...

  • Page 36: Adjust The Suction Levels

    Instructions for use SMARTair plus, SMARTair plus mobile 6 Operation | 6.4 Adjust the suction levels 6.4 Adjust the suction levels ▶ Press the keys ⑦ and ⑧ to adjust the suction levels ① to ④. 6.4.1 Save the default suction level (as of software version 2) Note As of software version 2.0, the suction level can be saved and is retained after the...

  • Page 37: Setting The Response Sensitivity

    Instructions for use SMARTair plus, SMARTair plus mobile 6 Operation | 6.5 Setting the response sensitivity You can now save the suction level. ▶ Turn off the power switch ⑤ or ⑥, and turn it on after two seconds. The selected suction level is saved.
  • Page 38 Instructions for use SMARTair plus, SMARTair plus mobile 6 Operation | 6.5 Setting the response sensitivity Setting and saving the response sensitivity ▶ Turn on the power switch on the control unit. ▶ Start the working device at a speed of 5,000 to 7,000 rpm and keep it running while performing the setting.

  • Page 39: Cleaning And Servicing

    7 Cleaning and servicing | 7.1 Cleaning 7 Cleaning and servicing To guarantee constant readiness for use and maintenance of value of the KaVo product, the recommended servicing must be done. This device contains harmful dust. Only professionals and wearing the appropriate protective equipment may empty and service the device including emptying the dust collector.

  • Page 40: Exchange The Filter Bag Of The Smartair Plus Mobile

    7 Cleaning and servicing | 7.2 Servicing Prepare the unit ▶ Switch the power switch ③ to "Off". ▶ Pull out the SMARTair plus from the frame ① until the stop, and remove the cover ②. Exchanging the filter bag ▶...

  • Page 41: Changing The Adsorption Filter Of The Smartair Plus

    Prepare the unit ▶ Switch the power switch to "Off". ▶ Place the SMARTair plus mobile in a horizontal position. ▶ Slightly pull apart the grip strips ② to unlock the snap locks. ▶ Remove the cover ① of the SMARTair plus mobile.
  • Page 42 ▶ Switch the power switch ① to "Off". ▶ Pull the power plug and connecting line to the unit. ▶ Remove the SMARTair plus from the frame ④ or system base, and place it horizontally on the table. ▶ Press in the seal to the housing cover ②, and remove the housing cover ③.

  • Page 43: Changing The Adsorption Filter Of The Smartair Plus Mobile

    Instructions for use SMARTair plus, SMARTair plus mobile 7 Cleaning and servicing | 7.2 Servicing ▶ Insert the SMARTair plus into the frame or system base, and connect. See also: 4.2 Installing the SMARTair plus, Page 23 7.2.4 Changing the adsorption filter of the SMARTair plus mobile Note The adsorption filter must be changed every six months.

  • Page 44: Changing The Ultrafine Filter Of The Smartair Plus

    ▶ Close the filter flap ② (make sure it locks in place). ▶ Mount the cover for the SMARTair plus mobile and snap it in place. ▶ Set up the SMARTair plus mobile at the provided location and connect it.
  • Page 45 ▶ Switch the power switch ① to "Off". ▶ Pull the power plug and connecting line to the unit. ▶ Remove the SMARTair plus from the frame ④ or system base, and place it horizontally on the table. ▶ Press in the seal to the housing cover ②, and remove the housing cover ③.
  • Page 46 Instructions for use SMARTair plus, SMARTair plus mobile 7 Cleaning and servicing | 7.2 Servicing Remove the old ultrafine filter ▶ Loosen and fold back the two clamping strips on the ultrafine filter ①. ▶ If possible, bring the house into the open.
  • Page 47 Instructions for use SMARTair plus, SMARTair plus mobile 7 Cleaning and servicing | 7.2 Servicing Reinstall the muffler element/adsorption filter ▶ Insert a new muffler element ① or adsorption filter ②. ▶ Close the filter flap ①. Make sure that the snap locks ② lock in place.

  • Page 48: Changing The Ultrafine Filter Of The Smartair Plus Mobile

    ▶ Move the SMARTair plus mobile back into operating position. 7.2.6 Changing the ultrafine filter of the SMARTair plus mobile Note The SMARTair plus mobilemay only be operated when the ultrafine filter is inserted. Note The ultrafine filter must be changed every two years.
  • Page 49 Instructions for use SMARTair plus, SMARTair plus mobile 7 Cleaning and servicing | 7.2 Servicing Remove the muffler element/adsorption filter ▶ Undo the snap locks ②, and open the filter flap ①. ▶ Remove the muffler element ③ or adsorption filter ④.
  • Page 50 Instructions for use SMARTair plus, SMARTair plus mobile 7 Cleaning and servicing | 7.2 Servicing Install a new ultrafine filter. ▶ Insert the new ultrafine filter into the housing with the opening facing downward. ▶ Fix the ultrafine filter with the two clamping strips.
  • Page 51 ▶ Close the filter flap ①. Make sure that the snap locks ② lock in place. ▶ Remount the housing cover and lock in place. ▶ Connect the power cable and connecting line of the extraction system to the unit. ▶ Move the SMARTair plus mobile back into operating position. 49/57...

  • Page 52: Safety Check

    Note KaVo recommends checking function annually and observing the sections "Clean‐ ing and servicing" and "Troubleshooting" in these instructions for use. See also: 7 Cleaning and servicing, Page 37...

  • Page 53: Troubleshooting

    Instructions for use SMARTair plus, SMARTair plus mobile 9 Troubleshooting 9 Troubleshooting DANGER Electrical power. Risk of fatal injury. ▶ Have the electrical part of the device repaired and serviced only by professio‐ nals or persons trained at the factory who have been advised of the safety instructions.

  • Page 54: Accessories

    Instructions for use SMARTair plus, SMARTair plus mobile 10 Accessories 10 Accessories Presentation Brief description Mat. No. Foot switch (Mat. no. 1.000.3147) Connection line for K-Control (Mat. no. 1.000.7198) Adsorption filter (Mat. no. 0.658.1861) Ultrafine filter (Mat. no. 0.658.9802) Filter bag, package with 5 units for all dust extraction systems (Mat.

  • Page 55: Replacement Parts

    Instructions for use SMARTair plus, SMARTair plus mobile 11 Replacement parts | 11.1 Replacement parts for the SMARTair plus 11 Replacement parts 11.1 Replacement parts for the SMARTair plus 53/57...
  • Page 56 Instructions for use SMARTair plus, SMARTair plus mobile 11 Replacement parts | 11.1 Replacement parts for the SMARTair plus 1.000.7198 1.001.8191 0.658.1861 1.000.3147 0.658.9802 DE 1.002.2525 0.658.2160 (5 Stk.) GB 1.002.2529 CH 1.002.2527 US 1.002.2528 AUS 1.002.253 0 0.228.3076 (50 St.) DE 1.001.8593...

  • Page 57: Replacement Parts For The Smartair Plus Mobile

    Instructions for use SMARTair plus, SMARTair plus mobile 11 Replacement parts | 11.2 Replacement parts for the SMARTair plus mobile 11.2 Replacement parts for the SMARTair plus mobile 55/57...
  • Page 58 Instructions for use SMARTair plus, SMARTair plus mobile 11 Replacement parts | 11.2 Replacement parts for the SMARTair plus mobile 1.001.8191 1.000.7198 0.658.1861 1.000.3147 mtr. 0.065.7552 0.658.9802 0.695.1402 2x 0.224.6596 ø 42 1,2 m ø 48/42 0.658.2160 (5 Stk.) 1.002.1220 0.228.3076 (50 St.)

  • Page 59: Statement Of Conformance

    Instructions for use SMARTair plus, SMARTair plus mobile 12 Statement of conformance 12 Statement of conformance 57/57...
