8.2.4.2

Setting own ship's parameters

Set the following items in the [Ship's Parameters] dialog.
Setting Item
Ship's Name
Length (of ship)
Beam (ship's width)
Height from keel to MAX point
Keel-Trans
(distance between the transducer
and the keel)
MAX Course Change
(limit value of course change
angle)
MAX Speed Limit
MIN Speed Limit
MAX ROT
MIN ROT
MIN Turn Radius
Synchronizing setting
The [Ship's Parameters] dialog enables common setting items and individual setting items for RADAR,
ECDIS, and Conning (called a task station individually). Once common items are set in any of the task
stations, RADAR, ECDIS, and Conning, the settings are reflected (synchronized) in other task stations.
By setting common items in the state where all the task stations are active, the common setting items
are synchronized in all the task stations.
Section 8 Adjusting and Setting Up Equipment (for Services)
Description of Setting
Enter own ship's name in the box.
Enter own ship's length in the box.
Enter own ship's beam in the box.
Enter the height of the ship from the
keel to the maximum point in the box.
Enter the distance between the
transducer of the depth sounder and
the keel. (Required when displaying the
water depth with the keel fixed)
Enter the limit value of the course
change angle of the planned route in
the box.
Enter the ship's maximum speed in the
box.
Enter the ship's minimum speed in the
box.
Enter the maximum rate of turn in the
box.
Enter the minimum rate of turn in the
box.
Enter the minimum turn radius in the
box.
8-14
Setting Value
Max. 20 characters
1.0 to 1022.0 m
1.0 to 126.0 m
1.0 to 126.0 m
0.0 to 20.0 m
20.0 to 359.9°
10.0 to 99.9 kn
0.0 to 89.9 kn
30.0 to 1200.0°/min
0.0 to 570.0°/min
0.00 to 9.99 NM
