2. On the DSR page, enter values for the parameters indicated in
Note
Table 2-17. DSR Configuration Parameters (not associated with any DSRs)
Web Page Item
Remote Relay Settings
Discovered Remote Relays
Product Type
IP Address
MAC Address
Serial Number
Name
Version
Note
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Description
The settings in this section will activate an associated door strike relay. If a door
strike relay is not associated with the device, then you will only see the words Not
associated with any DSRs.
Click the Save button to save your configuration settings.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of the web page
items. First click on the Toggle Help button, and you will see a question mark (
appear next to some of the web page items. Move the mouse pointer to hover over a
question mark to see a short description of a specific web page item.
The Discovered Remote Relays section lists all of the networked door strike relays
on the network. To associate your device with a door strike relay, click on the
Associate button. This action allows the user to configure the door strike relay. Keep
in mind that a device may only be associated with one door strike relay.
Displays the product type of the remote relay.
Displays the IP address of the remote relay.
Displays the MAC address of the remote relay.
Displays the serial number of the remote relay.
Displays the name of the remote relay.
Displays the version of the remote relay.
Use this button to search for and find any remote relays that are available on the
network.
Use this button to view the settings of a remote relay that has been "discovered" after
pressing the Discover button.
Use this button to associate the remote relay with the device. Only one relay may be
associated with a device.
Use this button to disassociate the remote relay from the device. Only one relay may
be associated with a device. This button is only available when a relay is associated
with a device.
Associating a DSR does not require a reboot. However, you should reboot the device after
disassociating a DSR.
