Web Page Item
Relay Pulse Code
Relay Pulse Duration (in seconds)
Relay Activation Code
Relay Deactivation Code
Play tone during DTMF Activation
Activate Relay During Ring
Activate Relay During Night Ring
Activate Relay While Call Active
Misc Settings
Device Name
Auto-Answer Incoming Calls
Play Ringback Tone
Disable HTTPS (NOT recommended)
Singlewire Broadcast Strobe Settings
Priority
Scene
Operations Guide
Table 2-8. Device Configuration Parameters
Description
DTMF code used to pulse the relay when entered on a phone during a
SIP call with the device. Relay will activate for Relay Pulse Duration
seconds then deactivate. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).
The length of time (in seconds) during which the relay will be activated
when the DTMF Relay Activation Code is detected. Enter up to 5 digits.
Activation code used to activate the relay when entered on a phone during
a SIP call with the device. Relay will be active indefinitely, or until the
DTMF Relay Deactivation code is entered. Activate Relay with DTMF
Code must be enabled. Enter up to 25 digits (* and # are supported).
Code used to deactivate the relay when entered on a phone during a SIP
call with the device. Activate Relay with DTMF Code must be enabled.
Enter up to 25 digits (* and # are supported).
When selected, the device will play a tone out of the speaker upon DTMF
relay activation. The tone plays for the DTMF Activation Duration (in
seconds).
When selected, the relay will be activated for as long as the device is
ringing. When Auto-Answer Incoming Calls is enabled, the device will not
ring and this option does nothing.
When selected, the relay will be activated as long as the Nightringer
extension is ringing.
When selected, the relay will be activated as long as the SIP call is active.
Type the device name. Enter up to 25 characters.
When selected, the device will automatically answer incoming calls. When
Auto-Answer Incoming Calls is disabled, the device will play a ring tone
(corresponds to Ring Tone on the Audiofiles page) out of the speaker.
When selected, the device will play a ringback tone (corresponds to
Ringback Tone on the Audiofiles page) out of the speaker while placing an
outbound call. The Ringback Tone will play until the call is answered.
Disables the encrypted connection to the webpage. We do not
recommend disabling HTTPS for security reasons.
Note This setting requires a reboot for the changes to take effect.
For up to 10 Singlewire pages, when a priority is specified for the page, a
corresponding strobe scene will be activated. The color may be selected
from the drop down menu, or customized by the user with the 0-255 scale.
Brightness is specified with a value between 0 and 255.
The following strobe settings will only appear if a CyberData Strobe
product is connected to your device. If a CyberData Strobe product
is not connected to your device, you will not see the strobe settings.
Indicates the priority of the Singlewire broadcast, with 1 the highest
priority and 10 the lowest.
Use this section to select the strobe flashing behavior for the Singlewire
Broadcast.
