To set up WAN failover to 3G, first go to the WAN Settings page of the web console and input the following settings.
MANAGEMENT
FATBOX_G3
3. 14
WAN FAILOVER TO 3G
MENU OPTIONS
Quick Start
LAN Settings
WAN Settings
Port Forwarding
Dynamic DNS
IPsec VPN
Port Settings
IoT Hardware
IoT Client
SNMP
Management
System Status
Logout
Then set in LAN Settings page, your device IP as client in local Ethernet network as per below example.
Note that some firewall will block unregistered device with manual IP setting.
FATBOX_G3
MENU OPTIONS
Quick Start
LAN Settings
WAN Settings
Port Forwarding
When G3 powers up, internet will be routed thru ETH1 to the Gateway. When auto-ping fails, the box will reboot and switch to 3G/4G as backup.
In 3G/4G backup mode, the box will test ETH1 for ping (as set in AUTOPING) every 60s. If the ping test passes, the box will reboot and go back to ETH
WAN.
Advanced Settings
Enable Reboot on Ping Failure Enabled
SIM2 Enable Disabled
Remote PING Host IP address
8.8.8.8
PING Retry Time Period(s)
15
PING retries
4
Primary WAN Interface Ethernet
UPDATE
ETH1 IP Address
100.10.10.10
ETH1 Netmask
255.255.255.0
ETH1 Gateway
100.10.10.1
UPDATE
For Ethernet WAN Option
fatbox G3
Enable the FATBOX to reboot upon the
failure to PING your selected IP address
Set "Ethernet" as the Primary WAN Inter-
face
UPDATE the FATBOX
UPDATE and restart FATBOX
