AMPLIFIED ENGINEERING fatbox G3 Manual page 24

WEB
MANAGEMENT
FATBOX_G3
MENU OPTIONS
3. 12
MANAGEMENT
Quick Start
LAN Settings
WiFi & BT Settings
WAN Settings
Port Forwarding
Dynamic DNS
IPsec VPN
Port Settings
IoT Hardware
IoT Client
SNMP
Management
System Status
Logout
CROSS COMPILE C CODE
The FATBOX G3 is an open
Linux platform where user can
deploy their own portable codes
e.g. in C or Python or LUA to
run on an industrial cellular (3G
or 4G/LTE) and ethernet WAN
connected gateway device.
System Management
Configuration Parameters Management
Please insert usb drive labelled'FATBOX'.
Configuration files located in /config folder.
Upload /config from FATBOX Download /config to FATBOX
User Configuration and Scripts Management
Please insert usb drive labelled'FATBOX'.
Files (e.g. firewall.user, user.lua, user.py or
connstr.txt) must be in /user folder.
Download /user to FATBOX Execute user.lua Script
Delete User files Execute user.py Script
[G3 Lua.pdf]
[G3 Python.pdf]
fatbox G3
To allow 'cloning' of parameter settings to
multiple FATBOX in production
environment, we utilise USB flash drives.
This ensure only with physical access to
the device and the settings (with sensitive
data) be uploaded from a production
FATBOX.
1. Format a USB thumb-drive (e.g. FAT32)
and label it 'FATBOX'
2. After FATBOX is powered up and stable
condition (e.g. signal strength LEDs are
functioning), insert the thumb-drive into
USB port (at antenna end of box)
3. Click 'Upload from FATBOX', wait 5 sec,
remove thumb-drive
4. Insert thumb-drive into new FATBOX
(in stable operating condition) and click
'Download to FATBOX', wait 5 sec and
remove thumb-drive
5. Check in new FATBOX that parameters
from other FATBOX has been copied over
To input your own LUA or Python program:
1. Write your LUA or Python program and
name it as 'user.lua' or 'user.py'
2. Save the program in /user folder in
your thumb-drive (drive labelled
'FATBOX')
3. Insert the thumb-drive into FATBOX (in
stable operating condition)
4. Click 'Download /user to FATBOX',
wait 5 sec, and remove thumb-drive
5. You can click 'Execute Program' to test
you program
Your program will automatically be
executed after complete boot-up of the
FATBOX.
