hygena Matrix Large Sideboard Assembly Instructions Manual page 5

Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
Locking Pin x 18
D
Dowel 30mm x 24
G
15mm Screw x 20
J
Right drawer runner x 2
M
45mm Screw x 16
P
15mm Screw x 2
S
Left hinge set x 2
V
S
Door catch set screw x 8
S Y
Pad x 2
Tools required
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
7mm Masonary drill bit
(for use with wall plug)
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35
B
15mm Locking nut x 10
E
12mm Screw x 20
H
Left drawer runner x 2
K
Right side runner x 2
N
Wall plug x 2
Q
25mm Screw x 2
T
Counterplate x 2
S W
Ease door assembly spring x 4
40 45 50 55 60 65 70 75
Small
hammer
Drill
(Drill holes
for wall plug)
80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
C
12mm Locking nut x 8
F
38mm Screw x 13
I
Left side runner x 2
L
Shelf support x 8
O
Wall strap x 2
R
Right hinge set x 2
U
Door catch set x 2
S X
60mm Screw x 12
Ruler/tape
measure
Eye protection
(when using a
hammer or glue)
4
