Bergen 2 drawer bedside chest
Assembly Instructions
Dimensions
Width - 45.5cm
Depth - 38.1cm
578/5344 WHT/Mirror
571/3440 HG WHT
Height - 43.9cm
241/6757 OAK
226/4088 WHT
248/5881 WAL
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928
For any other queries please contact the Customer Helpline on: 0345 640 2020
- Please keep for future reference
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
241/6757
226/4088
248/5881
571/3440
578/5344
Issue 3 - 28/04/16
Advertisement
Related Manuals for hygena 241/6757
Summary of Contents for hygena 241/6757
- Page 1 Depth - 38.1cm 578/5344 WHT/Mirror 571/3440 HG WHT carton(s) it was packed in. Height - 43.9cm 241/6757 OAK 226/4088 WHT 248/5881 WAL Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number)
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on •To reduce the components and tools listed on the product, this could cause likelihood of damaging your pages 2 and 3. - Page 3 Components - Panels For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the panels listed below Left & Right Side x 2 Bottom (38.7 x 38cm) (45.5 x 38.1cm) (45.5 x 38.1cm) P2028 P1985 P1986 Drawerfront x 2...
- Page 4 Components - Fittings For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. FK1012 FK1011 FK1010...
- Page 5 Assembly Instructions Step 1 If Highgloss, Prepare the drawer Please remove the protective film! fronts Screw 2 locking screw B into the holes shown on the back of each drawer front 5 . Note: Insert locking screw B as far as shown. Do not over tighten.
- Page 6 Assembly Instructions Step 1 continued finishing the drawers Turn over drawer and slide drawerbase supports I in corner as shown and fix them, using the attached screws . Step 2 Attaching runners Fix runner left and right side A J and M on left & right side 1 as shown using 10mm fixing screw drawer D and...
- Page 7 Assembly Instructions Step 3 Attach bottom and foot Position bottom 3 onto foot 4 and fix with 30mm chipboard screw F. Screw 24mm locking screws B into bottom 3 . Note: Insert locking screw Bas far as shown. Do not over tighten. Finished front edge Step 4...
- Page 8 Assembly Instructions Step 5 Slide in foldy back Slide foldy back 9 into the grooves in left & right side 1 . Step 6 a: Prepare top Screw 4 locking screw B into the holes shown on top Note: Insert locking screw Bas far as shown.
- Page 9 Assembly Instructions Step 6 continued Attaching top Position top 2 onto left & right side 1 . Use a screwdriver to turn locking nuts A clockwise to lock. Step 7 Fixate foldy back Turn over chest and slide drawerbase supportsI in corner as shown and fix them, using the attached screws .
- Page 10 Assembly Instructions Step 8 Attaching runners Fix runner left and right side B K and N on left & right drawer side 6 and 8 as shown using 12,5mm pozi screw E. Step 9 Attaching drawer handle Attacht drawer handle L on drawer front 5 as shown using 12,5mm pozi screw E.
