Range Kitchen -

Assembly Instructions -

hygena

Monza

Dimensions

Width - 60cm

Depth - 59cm

Height - 213cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

600mm Larder Cabinet

Please keep for future reference

Imola

Ricadi

656/5817

Pesaro

MADE IN

BRITAIN

Issue 2 - 16/02/11

Need help?

Do you have a question about the Monza and is the answer not in the manual?

Questions and answers

Summary of Contents for hygena Monza

Page 1 Range Kitchen - 600mm Larder Cabinet Assembly Instructions - 656/5817 Please keep for future reference hygena Ricadi Monza Pesaro Imola Dimensions Width - 60cm Depth - 59cm MADE IN Height - 213cm BRITAIN Important - Please read these instructions fully before starting assembly...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 47kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Back (DPF106A) (DPF107A) (DPF109A) (1980 x 560mm) (1980 x 560mm) (579 x 1976mm) Loose Shelf...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 (596 x 716mm) (596 x 716mm) (596 x 716mm) The front surface of this door is protected with a peel-off film Monza Larder Door Imola Larder Door Ricadi Larder Door Pesaro Larder Door (DPF125A) (596 x 1258mm) (DPF125A) (596 x 1258mm)
Page 6 656/6555 Pesaro Cream 656/6586 Pesaro Oak 656/6579 Ricadi 656/6593 Imola Door Handle (F131) 25mm Screw F132) 25mm Screw Monza Door Handle (F123) F132) 25mm Screw F132) 25mm Screw Hole Plug F132) (F114) Pesaro Door Handle Ricadi Door Handle (F125) (F126)
Page 7 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Choose which way If you would If you would you would like the like your doors like your doors doors to open to open this to open this...
Page 8 Assembly Instructions Step 3 Prepare the right side Refer to step 1 and, if required, fit 5 hinge plates onto the right side , as shown. Screw 6 metal dowels into the holes shown on the right side Fit a bracket to the right side , flush with...
Page 9 Assembly Instructions Step 5 Fit the legs to the base Push the leg sockets into the holes in the base as shown. Secure each leg socket with 3 screws Tap in the centre plug on each leg socket Push the leg into the leg socket Step 6...
Page 10 Assembly Instructions Step 7 Prepare the fixed shelf Insert 4 large locking nuts into the fixed shelf as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 6 wooden dowels into the fixed shelf Note: Wooden dowels must not stick out from the edge by more than...
Page 11 Assembly Instructions Step 9 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the large locking nuts fitted to the base , top fixed shelf Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
Page 12 Assembly Instructions Step 11 Secure the back The bottom edge of the back must be flush with the bottom edge of the base Secure the back the unit using 3 screws into the back edge of the base , fixed shelf and top Stand the unit up for the next stage.
Page 13 Assembly Instructions Step 13 Joining units together Fittings have been supplied so you are able to join units together. Make sure that your first unit is level. Push the other unit up against first unit and ensure both units are level.
Page 14 Assembly Instructions Step 15 Important: If you have the Ricadi Doors, please refer to step 19 for the hinge arm positions. Prepare the doors Push fit 2 hinges into the door and 3 hinges into the larder door Secure each hinge with 2 screws Note: Before securing with the screws, make...
Page 15 Assembly Instructions Step 16 MONZA DOORS ONLY Carefully choose which 2 holes you will need to drill in each door. Drill the handle holes Only drill the 2 holes shown here if you in the door have fitted the hinges to the LEFT side.
Page 16 Assembly Instructions Step 17 MONZA DOORS ONLY Carefully choose which 2 holes you will need to drill in each door. Drill the handle holes Only drill the 2 holes shown here if you in the door have fitted the hinges to the RIGHT side.
Page 17 Assembly Instructions Step 18 IMOLA DOORS ONLY Carefully choose which 2 holes you will need to drill in each door. Drill the handle holes Only drill the 2 holes shown here if you in the door have fitted the hinges to the LEFT side. Important: Please follow these instructions carefully.
Page 18 Assembly Instructions Step 19 IMOLA DOORS ONLY Carefully choose which 2 holes you will need to drill in each door. Drill the handle holes Only drill the 2 holes shown here if you in the door have fitted the hinges to the RIGHT side. Important: Please follow these instructions carefully.
Page 19 Assembly Instructions Step 20 RICADI DOORS ONLY Carefully choose which hole you will need to drill in each door. Drill the handle holes Only drill the hole shown here if you in the doors have fitted the hinges to the LEFT side. Important: Please follow these instructions carefully.
Page 20 Assembly Instructions Step 21 RICADI DOORS ONLY Carefully choose which hole you will need to drill in each door. Drill the handle holes Only drill the hole shown here if you in the doors have fitted the hinges to the RIGHT side. Important: Please follow these instructions carefully.
Page 21 Assembly Instructions Step 22 PESARO DOORS ONLY Carefully choose which 2 holes you will need to drill in each door. Drill the handle holes Only drill the 2 holes shown here if you in the door have fitted the hinges to the LEFT side. Important: Please follow these instructions carefully.
Page 22 Assembly Instructions Step 23 PESARO DOORS ONLY Carefully choose which 2 holes you will need to drill in each door. Drill the handle holes Only drill the 2 holes shown here if you in the door have fitted the hinges to the RIGHT side. Important: Please follow these instructions carefully.
Page 23 This Diagram shows monza doors and their handles being fitted. You may have chosen different doors and handles. If you need to seperate the hinge arm from the hinge plate,...
Page 24 Assembly Instructions Step 25 Adjust the doors if needed Height adjustment. Loosen screws A on hinge plates and move door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on hinge arm and move door in or out as required.
Page 25 Assembly Instructions Step 26 Fit the hinge covers Push the hinge covers onto the hinge arms Step 27 Fit the plinth Offer the plinth up to the unit and, using a pencil, mark the position of the unit’s legs on the back of the plinth.
Page 26 Fit other products to the unit To fit other products to this unit e.g. worktops etc., please follow the instructions packed with them. Monza Ricadi We recommend that you consult a qualified joiner or kitchen fitter. Assembly is complete Warning: The unit is heavy.
Page 28 ALR2520...
