Ajust The Tilt Tension Screws To Adjust The Tilt Angles Of Tv - Pipishell PILTK4 Installation Instructions Manual

4B-3
Use the hammer to
knock anchors [B] into
the wall.
Ajust the Tilt Tension Screws [S] to Adjust the Tilt Angles of TV
Step 5
Loosen the six tilt tension screws [S] on both brackets, adjust the hook of the
bracket to the desired angle, then tighten tilt tension screws with a wrench (not
included) and a screwdriver (not included) to fix the tilting angle of TV.
Install wall plate using lag bolts [A] and anchors [B].
Be sure the anchors [B] are seated flush with the
concrete surface. Tighten the lag bolts [A] only until
they are pulled firmly against the wall plate. DO NOT
over-tighten the lag bolts [A].
04
S
S
S
B
A
03
S
8
8mm Wrench
Tighten
S
Loosen
