Supplied Hardware

Hardware for Attaching Wall Plate to Wall

Lag Bolts
ST7X55
x4
A

Hardware for Attaching TV Bracket to TV

Washers
φ6mm
M4-5-6
M-H
Philips Screws
M4 x 12mm
M4 x 30mm
x4
M-A
Wall Anchor
φ10MM
x4
B
Spacers
L10mm
M-I
x4
Philips Screws
M6 x 15mm
M6 x 30mm
x4 x4
M-B M-C
CAUTION!
These anchors are for concrete
or brick walls ONLY. DO NOT use
them in drywall or wood studs.
Spacers
L5mm
x8
Philips Screws
M8 x 15mm
M8 x 45mm
M8 x 65mm
x4
M-E
M-D
2
M-J
x4 x4
M-F
x8
x4
M-G
