DC FUSE REPLACEMENT

The DC fuses may be replaced by inserting the tip of a flat-head screwdriver into the
fuse holder slot, and rotating the slot counter-clockwise. The fuse and its carrier will
then pop out.

FUSE RATINGS

The following table lists the required fuses:
Nominal
Fuses Mains
Voltage
115 V
#1, #2 (AC)
230 V
#3 (DC) N/A
#4 (DC) N/A
The recommended fuse manufacturer is Littelfuse (http://www.littelfuse.com).
Replacement fuses may be easily obtained from Digi-Key (http://www.digikey.com) and
other distributors.
Rating Case Size
1.6A, 250V,
5×20 mm
Time-Delay
0.8A, 250V,
5×20 mm
Time-Delay
1.0A, 250V,
5×20 mm
Time-Delay
6.3A, 250V,
5×20 mm
Time-Delay
Recommended Replacement Part
Littelfuse Part Digi-Key Stock
Number
021801.6HXP
0218.800HXP
0218001.HXP
021806.3HXP
16
Number
F2424-ND
F2418-ND
F2419-ND
F2428-ND
