SIG HERR FAIRCHILD 24 Assembly Instructions Manual

Advertisement

Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction.
1
Plan Sheet #1
2
White Tissue
1
Tailwheel Assy.
11 3/32" sq.x18" Balsa Strip
4
3/32"x1/4"x18" Balsa Strip
1
Plastic Propeller
1
Nylon Propeller Bearing
1
3/16"x60" Rubber Strip
Tools and Building Supplies
You will need the following items to assemble this model. You must read and follow all of the manufactures
instructions provided with these items!
-Glue
-Cutting Tools
-Clear Dope, Thinner & paint brush
-320 and 400 grit sandpaper
-Straight Pins
-Wax Paper
-Needle nose pliers
-1/4" Drill Bit
-Building Board
COMPLETE KIT PARTS LIST
1 Plan Sheet #2
1 Colored tissue
3 Plastic Windshield Material
2 1/8" sq.x18" Balsa Strip
1 3/16"x2" Birch Dowel
1 Propeller Shaft
2 Plastic Wheels
8 Laser Cut Sheets
CA, White Glue, Sigment or Ambroid all work well.
A hobby knife with a #11 blade is used for general cutting. A single edge
razor blade is also a useful cutting tool.
1
Decal Sheet
1
1/16"x12" Landing Gear Wire
22 1/16" sq.x18" Balsa Strip
5
3/32"x3/16"x18" Balsa Strip
1
Instruction Manual
2
Brass Washer
2
1/16" Plastic Wheel Retainers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HERR FAIRCHILD 24 and is the answer not in the manual?

Questions and answers

Summary of Contents for SIG HERR FAIRCHILD 24

  • Page 1 Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction. COMPLETE KIT PARTS LIST Plan Sheet #1 1 Plan Sheet #2 Decal Sheet White Tissue 1 Colored tissue 1/16"x12" Landing Gear Wire Tailwheel Assy.
  • Page 2 The first thing that you need to do is to identify and mark the part numbers on the laser cut parts using the drawings on the following pages as a guide. It is possible that several of the laser cut parts may not be completely cut through. If this is the case you can free the part from the sheet quickly using an X-acto knife.
  • Page 3 Beginners Note These instructions were written assuming that the builder has previous building experience. If this is your frrst model then we recommend that you purchase a copy of the following book: Rubber Powered Model Airplanes By: Don Ross This excellent book covers basic building and flying procedures and provides valuable information about all aspects of building and flying rubber powered model airplanes.
  • Page 4: Building The Tail Surfaces

    Building the Tail Surfaces Cover the plan with wax paper. Build the Rudder from laser cut parts R-1, R-2, R-3 and R-4. The remaining rudder structure is made from 3/32"sq. balsa strip. Build the Stabilizer from laser cut parts S-1, S-2 and S-3. The leading edge and trailing edges are made from 3/32" x 3/16" balsa strip.
  • Page 5 ,/tr> 23. Glue the two F-19 pieces to the front top of F-6. When the glue is dry, sand the F-19's flush with the F-1's on the fuselage sides. 24. Glue F-20A and F-20B to the rear of F-20. Bend the landing gear wire using the pattern on the plan. Glue the landing gear wire into the slot between F-20A and F-20B.
  • Page 6: Cover The Model

    48. Glue W-6, W-7 and W-8 together over the plan. 49. Raise the tip 3/32" from the building board at the tip and glue the tip to the leading edge and trailing edge. 50. Glue W-4 into position. 51. Glue the two 1/16" sq. balsa leading edge spars to the top of the wing. 52.
  • Page 7: Safety Rules

    LIMIT OF LIABILITY: In use of our products, Sig Mfg. Co.'s only obligation shall be to replace such quantity of the product proven to be defective. User shall determine the suitability of the product for his or her intended use and shall assume all risk and liability in connection...
