4. Put Weight Plates and Barbell Assembly in the Base, and Adjust Base End Shrouds
In order to avoid possible serious injury, when placing the Weight Plates in the Base Assembly, be careful to avoid fingers or
hands being caught or pinched.
NOTICE: Be sure that the Weight Plates are fully seated in the Base. Ensure there are no large gaps between Weight Plates, and all weight plate
tabs are aligned and locked together. Make sure the locking tab at the top of each Base End Shroud is seated in the selection lip at the
top of the back Weight Plate.
Push the shrouds inward. Tighten the inner screws. To tighten the outer screws, it may be necessary to remove the Barbell and Weight
Plates. This adjustment is important for proper function and easier re-racking. If the barbell is difficult to re-rack after assembly, it may
be necessary to repeat this process.
9 X6
X2
6mm
5. Final Inspection
Inspect your machine to ensure that all fasteners are tight and components are properly assembled.
Be sure to record the serial number in the field provided at the front of this manual.
Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Owner's
Manual.
X2
X2
6mm
8
Owner's Manual
9 X6
Selection lip
Locking tab
6mm
X2
6mm
