Bowflex SelectTech 2080 Assembly & Owners Manual page 7

2. Attach Base End Shrouds
Note: Do not fully tighten screws. Shrouds should still slide.
NOTICE: Use the inner set of screw holes in the Base Tubes to fit the 80-lb barbell configuration. If the Barbell will have the 40-lb Weight
Upgrade (the 120-lb configuration), use the outer set of screw holes in the Base Tubes.
5
3. Attach Adapter Plates to Barbell Handle and Curl Bar Handle
NOTICE: Ensure the Adapter Plates are oriented correctly. The screws must enter the countersink holes on the back of the plates.
D X8
X8
D
6mm
X8
A
8
8
6
7
7
Owner's Manual
5
8
Inner
Outer
8
