Output Power Curves - InMode System with BodyFX Handpiece Operator's Manual

Output Power Curves

The curves that follow depict the changes for each mode at specific power settings.
60
50
40
30
20
10
0
10 50
Figure 8.2 Peak Voltage Versus Power Setting
InMode BodyFX Operator Manual
RF Output vs Load
200 500 800
Load [Ω]
Figure 8.1 Output Power versus Impedance
Full Power
Half Power
1000
38
