Section 5 - System Operation; Device Start-Up; System Shutdown - InMode System with BodyFX Handpiece Operator's Manual

Section 5 - System Operation

This section of the manual explains how to start the device, operate it and turn it off.
Prior to using or connecting the Handpiece, inspect the System and
Handpiece electrodes for cleanliness and possible mechanical damage.

Device Start-Up

1. Connect the Handpiece to the Handpiece connector socket on the system.
2. Turn on Main Power switch at the rear panel.
3. Press the On-Off button on the control panel to turn the device on. The System loads
the software and enters the Login Screen.
4. Enter unique password to get access to the device. If password is correct the system
enters Menu Screen.
5. The system loads the software and enters a self-test mode. If any problem is detected
during the test the error message will appear (See Troubleshooting Section in this
manual). If the test is passed correctly then the system automatically enters the Menu
Screen.
6. Select the BodyFX option from the Menu,Screen and System will enter the
Treatment Screen.
7. Verify on the screen that Software version is properly displayed and connected
Handpiece type is recognized correctly.
8. Select treatment parameters - RF power and pulse width - using Up and Down keys.
9. Press the Mode key to switch to the Ready mode.
10. The System is ready for use. Step on footswitch to start the treatment.

System Shutdown

To shut down the system turn the power-switch off.
In case of an emergency, the system may be switched off instantly by pressing the red
Emergency Stop Button on the right side of the System's front panel.
InMode BodyFX Operator Manual 27
