- Page 1 FLOOR STAND INSTALLATION AND SETUP GUIDE...
- Page 2 The content of this manual is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by TouchTunes Interactive Networks. TouchTunes Interactive Networks assumes no responsibility or liability for any errors or inaccuracies that may appear in this document.
-
Page 3: Table Of Contents
Bringing the Playdium Floor Stand to a Location ....... . . -
Page 5: Welcome
Welcome This section introduces the Playdium Floor Stand, provides important safety information, and describes how to get customer support. Introducing the Playdium Floor Stand About this guide Disclaimer and important safety information Contacting TouchTunes Playdium Floor Stand Installation and Setup Guide 900857-001 Rev 00... -
Page 6: Introducing The Playdium Floor Stand
PhotoBooth features. About this guide This guide is intended for Operators of TouchTunes digital jukeboxes and their technicians, and TouchTunes technical support and field service personnel. It provides important information about the installation, setup, and operation of your new Playdium Floor Stand. -
Page 7: Disclaimer And Important Safety Information
TouchTunes Interactive Networks is not responsible for any damage resulting from the improper installation or connection of test kit components or any other external equipment to your kit. Nor is TouchTunes responsible for any damage caused during shipment (except the shipment to the original purchaser) or any damage caused •... -
Page 8: Contacting Touchtunes
The date/time of the problem. • Actions performed immediately before the problem occurred. • Any additional comments. If you need assistance with this or any other TouchTunes product, call technical support at 847-353-1954. We value your comments. Playdium Floor Stand Installation and Setup Guide... -
Page 9: Installing The Playdium Floor Stand
Installing the Playdium Floor Stand This chapter explains how to install the Playdium Floor Stand in a location, including how to assemble the Floor Stand, mount a Playdium on the Floor Stand, and connect the lighting and controls included in the Floor Stand. -
Page 10: Floor Stand Dimensions
Before you install the Floor Stand, check that you have received all of the hardware components and that the hardware components and items in the parts kit are in good condition. Verify that you have received these hardware components of the Playdium Floor Stand: Component... -
Page 11: Preparing Tools For Installation
Preparing Tools for Installation CAUTION: Do not attempt installation if any hardware component or item in the parts kit is damaged. Contact your distributor or TouchTunes to report the damage immediately and request replacement parts. You may require these tools to install the Floor Stand. Ensure that you have all the tools at hand before beginning the installation: •... -
Page 12: Assembling The Floor Stand
3. Parts kit 4. Lighting bar 2. Fit the two halves of the baseplate together. 3. Position the lower half of the Floor Stand into the recess on the baseplate. Playdium Floor Stand Installation and Setup Guide... - Page 13 6. Remove the screws holding the top panel to the top of the Floor Stand’s upper half, then pull off the top panel. This panel must be removed, otherwise it will prevent you from hanging Playdium onto the stand. Playdium Floor Stand Installation and Setup Guide 900857-001 Rev 00...
- Page 14 8. Insert the top half of the Floor Stand onto the support bars, and fasten it to the bars using four (4) screws provided in your parts kit. Playdium Floor Stand Installation and Setup Guide...
- Page 15 Floor Stand, but is not fastened with any screws. 11. Pull up the cable for the lighting bar, to have it ready to insert into the Playdium. You are now ready to mount Playdium onto the Floor Stand. Playdium Floor Stand Installation and Setup Guide 900857-001 Rev 00...
-
Page 16: Mounting Playdium Onto The Floor Stand
Floor Stand. Hang the chassis onto the two screws. Note: In the illustration above, the payment door has been removed to better show the mounting holes. Your chassis will have its payment door closed, at this point. Playdium Floor Stand Installation and Setup Guide... - Page 17 7. Verify that the chassis is mounted solidly to the Floor Stand, and can’t move or slide around on the mounting screws. 8. Insert the cables coming from the Floor Stand’s button panel and lighting bar into the bottom cable channel. Playdium Floor Stand Installation and Setup Guide 900857-001 Rev 00...
- Page 18 12. Any cabling that goes outside Playdium, including the power cable, network cable, speaker cables, and so on, should be routed through the bottom-right cable channel, through the bottom half of the floor stand, and out the opening at the bottom of the back of the floor stand. Playdium Floor Stand Installation and Setup Guide...
-
Page 19: Levelling The Floor Stand
Your Floor Stand-mounted Playdium is now ready to be turned on. Remember to lock the payment panel after you close it. Playdium Floor Stand Installation and Setup Guide 900857-001 Rev 00... - Page 20 Installing the Playdium Floor Stand Levelling the Floor Stand Playdium Floor Stand Installation and Setup Guide...
- Page 23 TouchTunes Interactive Networks, Inc. TouchTunes Interactive Networks, Inc. Technical Support 400 Sainte Croix Avenue, Suite 200 E 3455 Salt Creek Lane, Suite 100 847-353-1954 Montreal, Quebec, Arlington Heights, IL 60005 www.touchtunes.com Canada, H4N 3L4 Copyright © 2014 TouchTunes Interactive Networks...
