Cisco Catalyst 2.4 GHz and 5/6 GHz Dual-Band Polarization-Diverse Directional Patch Antenna (C-ANT9103=)

Contents of the Antenna and Bracket Kit

Figure 1 Contents of the Antenna Bracket Kit
1 Cap plug. Four are included in the kit.
1
2 / -inch stainless steel flat washer. Four are included in
4
the kit.
1
3 / -inch stainless steel split-lock washer. Four are
4
included in the kit.
5
4 / -inch stainless steel split-lock washer. Two are
16
included in the kit.
5
5 / -inch stainless steel flat washer. Two are included in
16
the kit.
6 M8 stainless steel serrated washer. Two are included in
the kit.
7 Mounting arm. One is included in the kit.
5
8 / -18 bolt. Two are included in the kit.
16
9 M5 x 0.8 bolt, 14.2 L. Four are included in the kit.
10 0.3125-18 nut. Two are included in the kit.
11 #8-18 stainless steel self tap screw. Four are included in
the kit.
1
12 #6-8, 1 / -inch anchor. Four are included in the kit.
4
13 Worm gear clamp hose. Two are included in the kit.
14 Mounting flanges required for installation. Two are
included in the kit.
