Stadium Antenna, 8-port, Tri-band Wi-Fi 6E with
GNSS (IW-ANT-PNL25610-R=)
This chapter contains the following sections:
•
•
•
•
•
Overview
The Stadium Antenna (IW-ANT-PNL25610-R=) is an 8-port tri-band directional panel antenna supporting
three 4x4 MIMO Wi-Fi 6E radios. It is designed to comply with the FCC's 21 dBm EIRP skyward limit across
the UNII-1, UNII-5, and UNII-7 bands.
This antenna is designed for large public venues such as stadiums and other environments such as outdoor
campus coverage, warehouses, and industrial sites.
Integrated high-rejection coexistence filters and a passive, L1 GNSS antenna enable concurrent 5–GHz and
6–GHz radio operation and AFC location reporting, respectively. The radome is IP67, UV-stabilized, and UL
94 V-0 rated.
Overview, on page 1
Technical Specifications, on page 3
Mechanical Drawings, on page 5
Radiation Patterns, on page 6
Installation Options, on page 7
Stadium Antenna, 8-port, Tri-band Wi-Fi 6E with GNSS (IW-ANT-PNL25610-R=)
1
