Cisco Aironet 2.4 GHz and 5 GHz
Dual-Band Polarization-Diverse Directional
Array Antenna (AIR-ANT2566D4M-R)
This document describes the Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna
(AIR-ANT2566D4M-R), and provides electrical specifications and mounting instructions.
The AIR-ANT2566D4M-R antenna is a four-port polarization-diverse array that operates over the 2.4 GHz and 5 GHz Wi-Fi
bands. It ships with an articulating mount for use on flat surfaces and masts, and is adjustable in both horizontal and vertical
planes. The radome can be painted using commonly available non-conductive spray paints, such as Krylon or Rust-Oleum.
The antenna is designed for use in indoor and outdoor environments with an approved Cisco Aironet access point that requires
four dual-band antennas.
The following information is provided in this document:
Azimuth and Elevation Radiation Patterns
Installation Notes
Contents of the Antenna and Bracket Kit
Dimensions of the Antenna and Brackets
Obtain Documentation and Submit a Service Request
Cisco Systems, Inc.
www.cisco.com
#
Advertisement
Related Manuals for Cisco Aironet AIR-ANT2566D4M-R
Summary of Contents for Cisco Aironet AIR-ANT2566D4M-R
- Page 1 The radome can be painted using commonly available non-conductive spray paints, such as Krylon or Rust-Oleum. The antenna is designed for use in indoor and outdoor environments with an approved Cisco Aironet access point that requires four dual-band antennas.
-
Page 2: Technical Specifications
Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Technical Specifications Antenna Type Dual-Band Polarization-Diverse Directional Array Operating Frequency Ranges 2.4–2.5 GHz 5.15–5.925 GHz Nominal Input Impedance 50 Ohms 50 Ohms Voltage Standing Wave Ratio (VSWR) -
Page 3: Safety Precautions
If you are installing an antenna for the first time, for your own safety as well as that of others, seek professional assistance. Your Cisco sales representative can explain which mounting method to use for the size and type of antenna you are about... - Page 4 They will remove it safely. If an accident occurs with the power lines, call for qualified emergency help immediately. For a listing of all the warning statements and their translations, see Translated Safety Warnings for Cisco Aironet Access Points http://www.cisco.com/c/en/us/td/docs/wireless/access_point/warnings/reference/guide/ap_warn1.html Installation Notes Antennas transmit and receive radio signals that are susceptible to RF obstructions and common sources of interference that can reduce throughput and the range of the device to which they are connected.
- Page 5 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Install the antenna away from microwave ovens and 2-GHz cordless phones. These products can cause signal interference because they operate in the same frequency range as the device to which your antenna is connected.
- Page 6 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Figure 2 Dimensions of the Antenna with Brackets and Cables 217.0 254.0 240.0 41.0 176.0 254.0 240.0 4.50 THRU ALL 36" 1" FROM BOTTOM EDGE OF RADOME...
- Page 7 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Figure 3 Locations of Screw Holes and Pressure Vent at the Back of the Antenna 62.0 83.1 PRESSURE RELEASE 4X M4x0.7 THREADED VENT INSERT...
-
Page 8: Installing The Antenna
Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Figure 4 Locations of the Screw Holes on the Articulating Mount Flange 4.50 62.0 83.1 Installing the Antenna You can install the antenna on a wall or ceiling (must be a flat surface), or on a pole with a minimum diameter of 2 inches (5.08 cm) and a maximum diameter of 5 inches (12.7 cm). - Page 9 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Deciding on a Mounting Location The antenna should be mounted clear of any obstructions to the side or front of the enclosure, which contains the radiating elements. Keep in mind that this antenna should be aimed at the intended coverage area. Therefore, you should mount the antenna such that the desired mechanical tilt is achieved.
- Page 10 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Orient the antenna correctly (note the arrow on the back of the antenna that indicates the top of the antenna). Use a flat-blade screwdriver to loosen or tighten the fasteners at the azimuth and elevation- adjustment pivots.
- Page 11 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Figure 5 Exploded View of Antenna and Bracket Hardware Assembly The articulating mount flange bracket that comes The end of the articulating mount arm, which attaches to attached to the back of the antenna.
- Page 12 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Figure 6 Close-Up View of the Azimuth and Elevation-Adjustment Pivots ANGULAR MARKINGS EVERY 5 , LABELS AT 30 & 60 ANGULAR DETENTS EVERY 5...
- Page 13 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Figure 7 Azimuth Adjustment 90° ADJUSTMENT MAST AZIMUTH ADJUSTMENT...
- Page 14 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Figure 8 Elevation Adjustment 55° ADJUSTMENT MAST ELEVATION ADJUSTMENT Mounting on a Pole or Mast NOTE: The pole or mast must be rigid enough to hold the weight of an antenna along with the associated forces produced by wind loads.
- Page 15 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) After the antenna is secured on the mast, adjust the azimuth (side-to-side position) and elevation (up-and-down position) of the antenna. Loosen the adjustment pivot bolts slightly to allow for adjustment.
- Page 16 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Flush Mounting on a Wall Without Mount Brackets You can flush mount the antenna on a wall. For this, you will need to discard the articulating mount flange brackets from the installation.
- Page 17 Cisco Aironet 2.4 GHz and 5 GHz Dual-Band Polarization-Diverse Directional Array Antenna (AIR-ANT2566D4M-R) Figure 10 Back of the Antenna with Flush Mounting Screw-Holes Locations Screw holes for flush mounting on a wall. Each hole takes Pressure release vent. an 8 x 1¼-inch screw.
