- Page 1 USER MANUAL HPS-300/600/1100/1600 PORTABLE POWER STATION HPS-300/600/1100/1600 For Your Safety Read and understand this manual before use. Keep this manual for future reference.
- Page 2 HPS-300/600/1100/1600 We are still constantly improving this power station, therefore, some parts of this power station may be changed in order to achieve the better quality, but the main functions and operations will not be alternated and changed. Your understanding would be greatly appreciated.
-
Page 3: Table Of Contents
HYUNDAI Table of Contents SAFETY ................................. GENERAL DESCRIPTION ............................. MAIN PARAMETERS ............................OPERATION CONTROL AND DESCRIPTION ..................... OPERATION ................................STORAGE AND DOWNTIME MAINTENANCE ..................... -
Page 4: Safety
11) Any repair must be carried out by the manufacturer or an authorized repair agent in order to avoid danger. Do not attempt to replace the internal battery with anything other than the authorized replacement battery available from HYUNDAI. 12) Use power station only with specifically designated battery pack. Use of any other battery packs may... -
Page 5: General Description
AC Output Port : Electric appliances such as Televisions, Laptops, Cooker, etc. * Electric appliances which you intend to use must be less than the device’s continuous output power. (HPS-300 : 300W / HPS-600 : 500W / HPS-1100 : 1000W / HPS-1600 : 1500W) -
Page 6: Main Parameters
HPS-300/600/1100/1600 3. MAIN PARAMETERS HPS-300 HPS-600 HPS-1100 HPS-1600 Capacity 25Ah (10.8V) 50Ah (10.8V) 100Ah (10.8V) 137.5Ah (10.8V) Battery type Rechargeable lithium-ion battery AC output Port 230V, 50Hz, Pure sine wave output (2×AC Port) Continue power 300W 500W 1000W 1500W Peak power... -
Page 7: Operation Control And Description
HYUNDAI 4. OPERATION CONTROL AND DESCRIPTION FRONT 1 DC ON/OFF status 2 AC charging indicator 3 Solar charging indicator 4 Battery display 5 AC output power 6 Operating time 7 AC ON/OFF status 8 TYPE-C output port 9 USB output port... -
Page 8: Operation
Second, you will need to check the capacity for the individual output ports. For example, the AC port of HPS-300 is monitored by an inverter that allows for 300W of continuous power. This means if your devic is a pulling more than 300W for an extended period of time, the portable power supply will shut off. - Page 9 NOTE: 1. For wall charging, recharge only with the charger specified by the manufacturer. 2. For solar charging, it is recommended to use HYUNDAI solar charger or unless must use solar charger as following specification. - DC output : 5~24V...
- Page 10 HPS-300/600/1100/1600 3) Jump starter * Smart Jumper Clamp(EC5 connector) is optional. a. Plug one end with EC5 connector (Optional) of the battery clamps into the jumping port of your power station. b. Connect the positive and negative polarities of the battery clamps to the positive and the negative polarities of car battery (Red to +, black to -).
- Page 11 HYUNDAI 4) Alarm information description a. Overload When the using output power is more than specific output power which the model can be applied, the alarm area will display “OVERLOAD”. It is necessary to reduce the power of the electronic devices. If the AC output is turned off at this time, Press the AC ON/OFF button again and restart.
-
Page 12: Storage And Downtime Maintenance
HPS-300/600/1100/1600 6. STORAGE AND DOWNTIME MAINTENANCE Failure to maintain your power station by following steps can result in battery damage. 1. Please charge your power station before storage and fully recharge it every 6 months at least. Store it in a cool and dry place. - Page 13 HYUNDAI Corporation 25, Yulgok-ro 2-gil, Jongno-gu, Seoul 03143 Korea Declare that the product detailed below : PORTABLE POWER STATION MODEL : HPS-300, HPS-600, HPS-1100, HPS-1600 Satisfies the requirements of the Council Directives : Low voltage directive 2014/35/EU Electromagnetic Compatibility 2014/30/EU...
- Page 14 HYUNDAI Corporation 25, Yulgok-ro 2-gil, Jongno-gu, Seoul 03143, Korea, Post Code : 03143 82 2 390 1114 www.hyundaicorp.com Copyright HYUNDAI Corporation All rights reserved. Made in P.R.C...
