Operation
MP-25 Electric Pump
Electric pump for applying water-based cementitious materials. For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
See Page 2 for model information.
Important Safety Instructions
Read all warnings and instructions in this and all
related manuals. Save these instructions.
3A3651A
EN
