Kids Sywell - Cabin Bed
Assembly Instructions -
NOT SUITABLE FOR CHILDREN
UNDER 4 YEARS OF AGE .
Dimensions
Width - 195cm
Depth - 95cm
Height - 53cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
WARNING
385/1775
365/7120
379/1316
376/6853
385/3845
357/6232
MADE IN
BRITAIN
Issue 3 - 23/01/15
Advertisement
Related Manuals for Argos Kids Sywell
Summary of Contents for Argos Kids Sywell
- Page 1 Kids Sywell - Cabin Bed Assembly Instructions - 385/1775 Please keep for future reference 365/7120 379/1316 WARNING 376/6853 NOT SUITABLE FOR CHILDREN UNDER 4 YEARS OF AGE . 385/3845 357/6232 Dimensions Width - 195cm Depth - 95cm MADE IN Height - 53cm...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 66kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Quadrant (DF2481) (543 x 160mm) Left Side Right Side (DF1658) (DF1659) Right Quadrant...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left upright Tap 2 wooden dowels Finished into the left upright front edge Place a runner on the left upright as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and...
- Page 8 Assembly Instructions Step 10 Prepare the fixed shelf Insert 4 large locking nuts into the fixed shelf Finished Note: The arrow on the front edge locking nut must point towards the hole in the edge of the panel. Step 11 Fit the fixed shelf to the right upright Push the fixed shelf...
- Page 9 Assembly Instructions Step 13 Fit the cross rail Tap a double metal dowel through the right upright and into the cross rail until it ‘’bottoms out’’. Use a screwdriver to tighten the large locking fitted to the cross rail Finished front edge Step 14 Prepare the centre...
- Page 10 Assembly Instructions Step 16 Fit the left upright Push the left upright onto the assembly. Use a screwdriver to tighten the 2 large locking nuts fitted to the fixed shelf Secure the left upright to the centre back using 2 screws Finished the allen key front edge...
- Page 11 Assembly Instructions Step 19 Prepare the left and right base Tap 2 wooden dowels Finished into the left base front edge the right base Insert a large locking Finished into the left base front edge and the right base Step 20 Fit the left and right base Push the left base...
- Page 12 Assembly Instructions Step 21 Prepare the 2 end backs Tap 2 wooden dowels into each of the 2 end backs Step 22 Fit the 2 end backs Push both of the end backs onto the assembly. Secure each end back to the uprights using 2 screws the allen key...
- Page 13 Assembly Instructions Step 24 Fit a bed base Push a bed base onto the uprights Secure the bed base to each upright using 2 screws the allen key Finished front edge Finished Step 25 front edge Fit the other bed base Push the other bed base onto the uprights and .
- Page 14 Assembly Instructions Finished Step 26 front edge Fit 2 hinge plates onto the left side , making sure that the slot is facing towards the finished front edge. Step 27 Fit 2 hinge plates onto the right side , making sure that the slot is facing towards the finished front edge.
- Page 15 Assembly Instructions Step 29 Fit a support rail Fit a support rail onto the right side using 2 screws and allen key Step 30 Prepare the back panel Tap 2 wooden dowels into the back panel Finished front edge...
- Page 16 Assembly Instructions Step 31 Note: Support the back panel and the support rail until the left side has been fitted in the next step. Fit the back panel and Finished the other support rail front edge Fit the back panel and the support rail onto the right side using 4 screws...
- Page 17 Assembly Instructions Step 33 Fit 6 plastic nails Tap 3 plastic nails into the bottom edge of each of the sides and . Step 34 Secure the back panel Fix 5 brackets to the holes in the bed base using screws Important: Make sure that you screw down into the top edge of the...
- Page 18 Assembly Instructions Step 35 Prepare the left and right quadrants Tap a wooden dowel into the left quadrant and the right quadrant Step 36 Fit the quadrants Fit the left quadrant onto the left side using 2 screws allen key Fit the right quadrant onto the right side using 2 screws...
- Page 19 Assembly Instructions Step 37 Secure the quadrants For each quadrant, fix 2 brackets to the holes in the bed base using screws Fix the brackets the quadrants using screws Step 38 Fit the drawer Slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer...
- Page 20 Assembly Instructions Step 39 Fit the loose shelves For each of the 2 loose shelves, insert 4 shelf studs into the holes shown in the sides and uprights. Lower the 2 loose shelves down onto the shelf studs Step 40 Prepare the 2 doors Push fit 2 hinges into...
- Page 21 Assembly Instructions Step 41 Fit doors and handles Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 22 Assembly Instructions Step 42 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 23 If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 24 ALR3139...
