Page 1
π H-3478 1-800-295-5510 uline.com DIGITAL POCKET SCALE OVERVIEW OF CONTROLS CONTROL PANEL JKD-500X0.1g TARE ZERO MODE CONTROL FUNCTIONS TARE ZERO MODE BUTTON MODE TARE ZERO ON/OFF Displays gross and Changes weigh Tares the weight of Sets display to zero. Turns the scale FUNCTION net weight.
Page 2
OPERATION TURNING THE SCALE ON/OFF COUNTING Press MODE to select “PCS.” • To turn the scale on, press the ON/OFF button. 2. Press N/G to choose the sampling amount: • To turn the scale off, press the ON/OFF button. 5=10 10 pieces CHANGING UNIT OF MEASURE 5=20...
Page 3
TROUBLESHOOTING OPERATING ISSUE RECOMMENDATION Confirm nothing is on the weighing platform and reboot the scale. Load cell failure. Confirm the shipping screw has been removed from the scale. (See Figure 1[B] ) HHHHH LLLLL Defective load cell. Defective mainboard. ErrE Reboot the scale.
