2. Installation

Step 1: Remove the knob and the cover plate.
Step 2: Always make sure that the electricity is switched off during installation. Then connect
the wires as indicated in the 'Connection diagram'.
Step 3: Now install the dimmer in the mounting box. Use screws or tighten the screws of the
mounting clamps.
Step 4: Switch the electricity back on. Switch on the connected lights by pressing the dimmer
shaft. Now adjust the 'MIN/MAX adjustment, as described under 'MIN/MAX installation'
Step 5: Optionally you may connect the dimmer to your SMART home system as indicated
under the heading "Connecting home automation / apps".
Step 6: Place back the cover plate and dimmer knob.

3. MIN/MAX adjustment

For the SMART dimmer to work optimally, you can adjust the lights
to the dimmer with the MIN and MAX adjustment. As soon as you start turning MIN and MAX
adjustment, the dimmer will automatically go to the minimum and maximum light range.
MIN adjustment: Switch on the lights with the push / turn button. When the lights are on,
insert a screwdriver in MIN
and turn to the left. When the light becomes unsteady, turn slightly back to the right so that
the light remains steady.
MAX adjustment: Switch on the lights with the push / turn button. When the lights are on,
insert a screwdriver in MAX and turn to the right. When the light becomes unsteady, turn
slightly back to the left so that the light remains steady.
