EcoDim Eco-Dim.07 Z-Wave User Manual page 23

3. Note for special commands
1) Z-Wave plus Info Command Report
Parameter
Z-Wave Plus Version
Role Type
Node Type
Installer Icon Type
User Icon Type
2) Association Group Info Command
Association is different to Inclusion. The Inclusion function of a device "includes" the device
into a network, allowing it to communicate with other network devices. The association
function "associates" two devices, enabling them to communicate directly without the need
for a central controller.
a) Association Group Name Command Report
Association
Groups
Group 1
Group 2
V1
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_ALWAYS_ON
ZWAVEPLUS_INFO_REPORT_NODE_TYPE_ZWAVEPLUS_NODE
ICON_TYPE_GENERIC_LIGHT_DIMMER_SWITCH
ICON_TYPE_GENERIC_LIGHT_DIMMER_SWITCH
Group Max
Name Nodes
Lifeline
5
Basic Set
5
Description
The ASSIC of Lifeline: 4C 69 66 65 6C 69 6E 65
1. When press and hold down "Reset" button
for 4S to reset the dimmer, send "Device
Reset Locally Notification CC" to associated
devices of this group to report factory reset
information.
2. When load state changes, send "Switch
Multilevel Report CC" to associated devices of
this group.
Basic Set: 42 61 73 69 63 20 53 65 74
1. Short press the knob turn on the dimmer
Sends Basic Set(0xFF) to associated devices
2. Short press the knob turn off the dimmer
Sends Basic Set(0x00) to associated devices
Value
