EcoDim Eco-Dim.07 Z-Wave User Manual page 4

Smart Dimmer Switch 200W LED
Item NO. Eco-Dim.07 Z-Wave
LED Indicator
Indicates resets and
when the dimmer is
in pairing mode
Min. Setting
To set the minimum
light level.
220-240V AC Output
√ Compatible with any Z-Wave or Z-Wave plus controller.
√ Power Consumption meter
√ Voice support (Amazon Alexa & Google Assistant / Homey)
√ Achieve the on/off and dimming function through separately physical button
√ Support Repeater Role, Firmware OTA and SmartStart.
√ Suitable for 0-200W LED
√ Suitable for all well-known brands of cover frames
√ Optimal dimmable & light stability
√ MIN and MAX light adjustment options
√ Suitable for 90% of all LEDs
√ Installation with provided 2 wires (no neutral wire required)
√ Soft start system
√ Noiseless dimming
√ Suitable for surface-mounted boxes & flush-mounted boxes with or without screw holes
Optional: to connect extra Push Buttons
P L
220-240V AC Intput
Reset Button
To set the dimmer to
factory settings or to
pair mode.
Max. Setting
To set the maximum
light level.
3
