- Page 1 Wireless Type-C/HDMI Extender Kit - 30m User's Guide P/N: USBCwireless G4-0076A...
- Page 2 Thank you for purchasing from gofanco. Our products aim to meet all your connectivity needs wherever you go. For optimum performance and safety, please read the instructions carefully and keep this User’s Guide for future reference. If you need more information about our products, please visit www.gofanco.com.
- Page 3 • Shut off power and make sure environment is safe before installation • Do not plug the HDMI cables in/out when the device is in use to avoid cable damage. Make sure they are plugged into the correct ports • Use the included DC5V power adapters only.
- Page 4 Features • Mid-range wireless extension ideal for meeting/conference room applications • Type-C input on the Transmitter (TX) and HDMI output on the Receiver (RX) • Type-C Transmitter unit powered by the Type-C source device • Supports up to 98 feet (30m) in 1080p with auto quality adjustment •...
- Page 5 Installation Requirements Type-C source device (Phone, tablet, computer, etc) HDMI display device (SDTV/Monitor, HDTV/Monitor, projector, etc.) Product Layout Figure 1: Transmitter (TX) 1. Type-C Input Connects to the source device's Type-C port On when the Transmitter and Receiver are 2. Connection LED linked properly On when Transmitter is powered by the Type-C 3.
- Page 6 Figure 2: Receiver (RX) 1. Power Adapter Jack Connects to the included power adapter On when powered on 2. Connection LED Blinks when wireless connection is linked 3. Data Transmission LED On when transmitting data, otherwise it's off 4. HDMI Output Connects to the HDMI display device 5.
-
Page 7: Hardware Installation
Hardware Installation Power off your HDMI display. Plug the Transmitter's Type-C connector into a Type-C port of the source device. Connect your HDMI display to the Receiver's HDMI Output with an HDMI cable (HDMI cable not included). Plug the included power adapter into the Receiver's power jack, then plug the power adapter into a reliable power source. - Page 8 Application Type-C Source (Phone, Computer) Receiver HDMI Transmitter Cable Display Power Adapter...
- Page 9 FAQ & Solutions The Transmitter and Receiver can't connect to each other: 1) Please check if the Connection LED on Transmitter and Receiver are blinking. 2) Power cycle the transmitter and receiver. 3) Make sure the HDMI cable is firmly connected to the display.
-
Page 10: Specifications
Specifications Item Specification HDMI Compliance HDMI 1.3 HDCP Compliance HDCP 1.2 480p@60Hz, 576p@50Hz, Resolution 720p@50/60Hz, 1080p@50/60Hz Bandwidth 10.2Gbps Wireless Transmission 5.0 GHz Wireless Latency <200ms Transmission Distance Up to 98ft (30 meters) Housing Material Plastic Power Adapter (RX only) Output: DC5V/2A Power Consumption TX: <3W / RX: <5W Operating Temperature... - Page 11 Disclaimer The product name and brand name may be registered trademarks of related manufacturers. TM and ® may be omitted on the user’s guide. The pictures on the user’s guide are just for reference, and there may be some slight differences with the actual products.
- Page 12 Thank you for choosing gofanco www.gofanco.com...
