Step 13 - Disassemble the
Housing Assembly
Remove the following screws:
Two (2) Buttons heads located
on the front of the printer on the
Two (2) Buttons heads that attach
the Floor plate to the Base Plate
(inside the Replicator+) using a
Pull the Floor Plate away from the
front of the Replicator+ to remove.
Remove the seven (7) thread
forming screws that attach the
Left and Right Panel to the Base
Plate.
Remove the six (6) thread forming
screw that attach the Left and
Right Panels to the Front Panel.

Step 14 - Remove the Camera

•
Remove the Camera by pushing on
the Camera Mount Clip that holds
it on to the Left Panel.
