SPECIFICATIONS: WATER-COOLED UNITS
General Arrangement Drawing:

Models HGEN1000W through HGEN1200W

MODEL
A B C
31.60 20.60 11.00
HGEN1000W
(802.7) (523.3) (279.4)
31.60 20.60 11.00
HGEN1200W
(802.7) (523.3) (279.4)
C
O
A
B
D
E
REAR VIEW
MCGUIRE AIR COMPRESSORS INC
DIMENSIONS, INCHES (MM)
D E F G H
26.77 28.35 41.34 45.28 41.34 38.68
(680) (720) (1050) (1150) (1050) (982.5)
26.77 28.35 41.34 45.28 41.34 38.68
(680) (720) (1050) (1150) (1050) (982.5)
K
L
E
H
COOLING
WATER
OUTLET
N
COOLING
WATER
INLET
M
J K L M N
6.59 3.35 6.40 9.84 1.97
(167.5) (85) (162.5) (250) (50)
6.59 3.35 6.40 9.84 1.97
(167.5) (85) (162.5) (250) (50)
G
J
TOP VIEW
F
G
LEFT SIDE VIEW
1-888-229-9999
COOLING WATER
INLET/OUTLET
INLET/OUTLET
CONNECTIONS
O CONNECTIONS
4" ANSI Flange 1" NPT
4" ANSI Flange 1" NPT
FRONT VIEW
1-888-229-9999
WEIGHT
Lb. (kg)
582
(264)
626
(284)
WETTED AIR INLET
DRIED AIR OUTLET
17
