INSTRUCTION MANUAL
Models:
HG 5-10, HG 15
Contents
GENERAL SAFETY INFORMATION ................................. 2
RECEIVING, MOVING, AND UNPACKING ....................... 2
INSTALLATION ............................................................... 3
INSTRUMENTATION ...................................................... 4
CONDENSATE DRAIN VALVES ....................................... 4
START-UP/OPERATION .................................................. 4
SHUTDOWN .................................................................. 4
MAINTENANCE ............................................................. 5
FIELD SERVICE GUIDE ................................................... 6
ENGINEERING DATA ..................................................... 7
ELECTRICAL SCHEMATIC ............................................... 7
WARRANTY .................................................................. 8
SERVICE DEPARTMENT: (724) 746-1100
HG SERIES
REFRIGERATED
COMPRESSED
AIR DRYERS
