SPECIFICATIONS: AIR-COOLED UNITS
General Arrangement Drawing:

Model HGEN600A

MODEL
A B
31.94 21.75 50.44
HGEN600A
(811.2) (552.4) (1281.3)
B
ON/OFF SWITCH, PCB
A
H
FRONT VIEW
8
MCGUIRE AIR COMPRESSORS INC
DIMENSIONS, INCHES (MM)
C D E F G
4.86 7.94 3.23 26.74
(123.5) (201.6) (82.0) (679.2)
COOLING
AIR FLOW
RIGHT SIDE VIEW
5-Ø10 MOUNTING HOLES
H J K L
20.24 4.18 40.94 49.26
(514) (106.2) (1040) (1251.2)
TOP VIEW
C
K J
L
FOOT PRINT
1-888-229-9999
INLET/OUTLET WEIGHT
CONNECTIONS Lb. (kg)
344
2" NPT
(156)
DRIED AIR OUTLET
WETTED AIR INLET
D E
F
G
HOLE FOR MAIN POWER
DRAIN OUTLET
REAR VIEW
