Deltech HYDROGARD Series Instruction Manual

Refrigerated type compressed air dryers

Hide thumbs

page of 20

/ 20
Bookmarks

Quick Links

Download this manual

5002940

Rev. A

6/07

Internal Use Only

5002730/060519

INSTRUCTION MANUAL

HYDROGARD

SERIES

Models:

HGD100, HGD125, HGD150, HGD200,

HGD250, HGD300, HGD400, HGD500,

HGE600, HGE750

CONTENTS

GENERAL SAFETY INFORMATION ......................... 2

RECEIVING, MOVING, AND UNPACKING ................ 2

1.0 INSTALLATION .................................................. 3

2.0 OPERATION ....................................................... 5

3.0 MAINTENANCE ................................................. 8

SIZING ...................................................................... 8

ENGINEERING DATA (Models 100-250) ................... 9

ENGINEERING DATA (Models 300-750) ................... 10

WIRING DIAGRAM (Models 100, 125 & 150 ) .......... 11

WIRING DIAGRAM (Models 200-600 - 460 VAC) ..... 12

WIRING DIAGRAM (Model 750 - 460 VAC) .............. 13

DIMENSIONS / WEIGHTS ........................................ 14

TROUBLESHOOTING GUIDE (Models 100-150) ..... 15

TROUBLESHOOTING GUIDE (Models 200-750) ..... 16

PARTS LIST .............................................................. 17

WARRANTY .............................................................. 20

SERVICE DEPARTMENT: (724) 746-1100

REFRIGERATED

TYPE

COMPRESSED

AIR DRYERS

Need help?

Do you have a question about the HYDROGARD Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Deltech HYDROGARD Series

Page 1 5002940 Rev. A 6/07 Internal Use Only 5002730/060519 INSTRUCTION MANUAL ® HYDROGARD SERIES Models: HGD100, HGD125, HGD150, HGD200, HGD250, HGD300, HGD400, HGD500, HGE600, HGE750 ® CONTENTS REFRIGERATED GENERAL SAFETY INFORMATION ......2 RECEIVING, MOVING, AND UNPACKING ....2 TYPE 1.0 INSTALLATION ..........3 2.0 OPERATION ............
Page 2 GENERAL SAFETY INFORMATION RECEIVING, MOVING, AND UNPACKING PRESSURIZED DEVICES: A. RECEIVING This equipment is a pressure containing This shipment has been thoroughly checked, packed and device. inspected before leaving our plant. It was received in good condition by the carrier and was so acknowledged. •...
Page 3 IMPORTANT: READ PRIOR TO STARTING THIS EQUIPMENT 1.0 INSTALLATION 1.1 Location For typical placement in a compressed air system, see drawing. Air compressor intake – Locate air compressor so that contaminants potentially harmful to the dryer (e.g. ammonia) are not drawn into the air system. C.
Page 4 1.2 Mounting Models 100-150: Separator has a knurled fitting with flexible drain tubing Mount the dryer on a level solid surface. Holes are provided in attached. Be sure knurled fitting is tightened by turning the dryer base to permanently mount the dryer to the floor. counter-clockwise before operating dryer.
Page 5 B. Condensate enters the reservoir (1) through the inlet port. C. Program Monitor When the condensate level in the reservoir covers the Press and hold Program Mode button until Main Menu screen capacitance sensor, an electronic signal is sent to the solid appears.
Page 6 pressure increases. Solid particulate load in the CONTROL PANEL compressed air supply will determine frequency of service. Typically element changeout is recommended at least annually. Push ESC button to exit program mode NOTE: If after 60 seconds no button is pressed while in Program Mode, the audible alarm sounds for five (5) seconds.
Page 7 D. Operating check points Check drain operation - push Drain (push-to-test) button to energize electric drain. A flow of condensate and/or Check that green Power-on light is illuminated air should be present at the drain outlet. Check that green Compressor-on light is illuminated if dryer is on in the manual mode or it is a scheduled on time Using the RS-232 port IMPORTANT: Refrigeration compressor must be restarted after...
Page 8 3.0 MAINTENANCE SIZING 3.1 Condenser coil – Clean off accumulated dust and dirt Determining dryer capacity at actual operating conditions monthly. To determine the maximum inlet flow capacity of a dryer at various operating conditions, multiply the rated capacity from 3.2 Moisture separator –...
Page 9 ENGINEERING DATA (Models 100-250) r i A y t i F ° t e l F ° t e l r i A r i a t e l ) r e ) g r t e l r i A r i a t e l ) r e...
Page 10 ENGINEERING DATA (Models 300-750) r i A y t i F ° t e l F ° t e l r i A r i a t e l ) r e ) g r t e l r i A r i a t e l ) r e...
Page 11 WIRING DIAGRAM Models 100, 125 & 150 Model 100 - 120/230 VAC 120 VAC POWER CORD SUPPLIED 230 VAC CUSTOMER SUPPLIED COMPRESSOR HARNESS OVERLOAD POWER ON PILOT LIGHT CAPACITOR MTR1 COMPRESSOR START RELAY GROUND STUD FAN 1 HARNESS FPS 1 FAN 1 MTR2 Models 125/150 - 120/230 VAC...
Page 12 WIRING DIAGRAM Models 200-600 - 460 VAC 460 VAC 3 PHASE 60 Hz FROM LINE 21 L1 L2 L3 TB1 L1 L2 L3 COMPRESSOR HARNESS CONT 1 COMPRESSOR MTR1 H4 H3 REF SHEET 01 LINE 20 208V REF SHEET 02 LINE 10 230V REF SHEET 02 LINE 11 400V...
Page 13 WIRING DIAGRAM Model 750 - 460 VAC 460 VAC 3 PHASE 60 Hz FROM LINE 21 TB1 L1 DISCONNECT SWITCH COMPRESSOR HARNESS CONT 1 MTR1 COMPRESSOR H4 H3 REF SHEET 01 LINE 20 208V REF SHEET 02 LINE 10 230V REF SHEET 02 LINE 11 400V FAN 1 HARNESS...
Page 14 DIMENSIONS / WEIGHTS Dimensions (inches) Model 37.56 37.56 37.56 38.60 38.60 45.38 45.38 58.06 58.06 58.06 25.62 25.62 25.62 32.15 32.15 32.15 32.15 32.15 32.15 32.15 1.63 1.63 1.63 1.88 1.88 2.63 2.63 2.77 2.77 2.77 23.62 23.62 23.62 30.15 30.15 30.15 30.15...
Page 15 TROUBLESHOOTING GUIDE (Models 100-150) SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION A) Water downstream of dryer 1. Residual free moisture remaining in Blow out system with dry air downstream pipelines 2. Air bypass system is open Check valve positions 3. Inlet and Outlet connections are reversed Check for correct connection 4.
Page 16 TROUBLESHOOTING GUIDE (Models 200-750) SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION A) Water downstream of dryer 1. Residual free moisture remaining in 1. Blow out system with dry air downstream pipelines 2. Air bypass system is open 2. Check valve positions 3. Inlet and Outlet connections are reversed 3.
Page 17 PARTS LIST t i n ) y l t i c c t i a i l t n i c t i i g i l a t t i n ) y l c t i c t i c t i c t i t l i...
Page 18 NOTES...
Page 19 NOTES...
Page 20 1415 California Avenue Canonsburg, PA 15317-1700 U.S.A. Brockville, ON , Canada , K6V 7H7 Phone: 724-745-8647 • Fax: 724-745-4967 Phone: 613-345-2280 • Fax: 613-345-7240 Email: deltech.inquiry@dehydration.spx.com Email: salescanada@dehydration.spx.com www.deltech-spx.com www.deltech-spx.com © 2007 SPX Dehydration & Process Filtration. All rights reserved.
