MCGUIRE AIR COMPRESSORS INC
SPECIFICATIONS: AIR-COOLED UNITS
General Arrangement Drawing:

Models HGEN1000A through HGEN1200A

MODEL
A B
31.60 20.60 11.00
HGEN1000A
(802.7) (523.3) (279.4)
31.60 20.60 11.00
HGEN1200A
(802.7) (523.3) (279.4)
C
A
B
D
E
REAR VIEW
10
MCGUIRE AIR COMPRESSORS INC
DIMENSIONS, INCHES (MM)
C D E F G
26.77 28.35 41.34 45.28
(680) (720) (1050) (1150)
26.77 28.35 41.34 45.28
(680) (720) (1050) (1150)
K
L
E
H
LEFT SIDE VIEW
H J K L
64.16 38.68 6.59 3.35
(1629.6) (982.5) (167.5) (85)
64.16 38.68 6.59 3.35
(1629.6) (982.5) (167.5) (85)
G
J
TOP VIEW
F
G
1-888-229-9999
INLET/OUTLET WEIGHT
CONNECTIONS Lb. (kg)
744
4" ANSI Flange
(337)
816
4" ANSI Flange
(370)
COOLING AIR FLOW
FRONT VIEW
1-888-229-9999
WETTED AIR INLET
DRIED AIR OUTLET
