SPECIFICATIONS: AIR-COOLED UNITS
General Arrangement Drawing:

Model HGEN800A

MODEL
A B
31.10 21.10 10.00
HGEN800A
(790) (536) (254)
C
A
B
D
E
REAR VIEW
MCGUIRE AIR COMPRESSORS INC
DIMENSIONS, INCHES (MM)
C D E F G
26.77 28.35 37.40 41.34
(680) (720) (950) (1050)
G
K
L
E
H
LEFT SIDE VIEW
H J K L
59.83 35.22 6.12 3.35
(1519.6) (894.5) (155.5) (85)
J
TOP VIEW
F
G
1-888-229-9999
INLET/OUTLET WEIGHT
CONNECTIONS Lb. (kg)
695
3" ANSI Flange
(315)
COOLING AIR FLOW
FRONT VIEW
1-888-229-9999
WETTED AIR INLET
DRIED AIR OUTLET
9
