Deltech HTD Series Instruction Manual

High inlet temperature refrigerated compressed air dryers

Advertisement

7610.724.28 Rev. B 12/06
Internal Use Only
724.27b/061250
INSTRUCTION MANUAL
Contents
1.0 INSTALLATION.........................................................2
2.0 OPERATION ............................................................3
3.0 MAINTENANCE.......................................................4
TROUBLESHOOTING GUIDE.............................................6
SPECIFICATIONS ......................................................... 7-8
ELECTRICAL SCHEMATICS ...............................................9
DIMENSIONS AND WEIGHTS ................................... 10-12
PARTS LIST.............................................................. 13-14
WARRANTY ..................................................................16
GENERAL SAFETY INFORMATION
1. Pressurized devices
This equipment is a pressure containing device.
• Do not exceed maximum operating pressure as
shown on equipment serial number tag.
• Make certain equipment is depressurized before
servicing.
2. Electrical
This equipment requires electricity to operate.
• Install equipment in compliance with national and
local electrical codes.
• Standard equipment is supplied with NEMA 1 elec-
trical enclosures and is not intended for installation
in hazardous environments.
• Disconnect power supply to equipment when per-
forming any electrical service work.
3. Breathing air
• Air treated by this equipment may not be suitable
for breathing without further purification. Refer to
OSHA standard 1910.134 for the requirements for
breathing quality air.
SERVICE DEPARTMENT: (724) 746-1100
HTD SERIES
HIGH INLET
TEMPERATURE
REFRIGERATED
COMPRESSED
AIR DRYERS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTD Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Deltech HTD Series

  • Page 1: Table Of Contents

    GENERAL SAFETY INFORMATION 1. Pressurized devices This equipment is a pressure containing device. • Do not exceed maximum operating pressure as shown on equipment serial number tag. HTD SERIES • Make certain equipment is depressurized before servicing. HIGH INLET 2. Electrical This equipment requires electricity to operate.
  • Page 2: Installation

    1.0 INSTALLATION 1.1 Location 2. Location in the compressed air system A. Air compressor intake - Locate air compressor so that Maximum working pressure - 250 psig, contaminants potentially harmful to the dryer are not 17.6 kgf/cm . Do not exceed unit’s Maximum Working drawn into the air system.
  • Page 3: Operation

    2.0 OPERATION D. Maximum flow capacity NOTE: Installations above 6000 feet, 1825 meters 1. For dryers without an aftercooler installed upstream Unit is adjusted to operate in altitudes up to 6000 feet, Flow capacity in scfm (m /min) @ 180°F, 82°C inlet 1825 meters.
  • Page 4: Maintenance

    3.0 MAINTENANCE 3.3 Replace separator/filter element yearly DRYER IS A PRESSURE CONTAINING DEVICE. DEPRESSURIZE BEFORE SERVICING. or more often if pressure drop across the dryer is excessive. 3.1 Ambient air filter - Clean accumulated dust and dirt from ambient air filter monthly or more often if air A.
  • Page 5 H. After making sure that O-ring and wave spring inside 3.4 Automatic condensate drain top of bowl are in place, reassemble bowl to head. • Check daily to be sure automatic drain is NOTE: Make certain O-ring is generously lubricated discharging.
  • Page 6: Troubleshooting Guide

    TROUBLESHOOTING GUIDE SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION A) Water downstream of dryer 1. Residual free moisture remaining in Blow out system with dry air downstream pipelines 2. Air by-pass system is open Check valve positions 3. Inlet and Outlet connections are Check for correct connection reversed 4.
  • Page 7 SPECIFICATIONS - Models 20 thru 75 Model Description Operating Conditions 60 / 50 Hz Rated Capacity scfm 20 / 17 25 / 21 35 / 27 50 / 50 75 / 61 60 / 50 Hz @125 psig, 8.8 kgf/cm /min 0.57 / 0.48 0.71 / 0.59...
  • Page 8: Specifications

    SPECIFICATIONS - Models 100 and 125 Model Description Operating Conditions 60 / 50 Hz Rated Capacity 100 / 83 125 / 104 scfm /min 60 / 50 Hz @125 psig, 8.8 kgf/cm 2.83 / 2.35 3.54 / 2.95 Maximum Working Pressure 250 psig (17.6 kgf/cm Maximum Inlet Temperature 180°F (82°C)
  • Page 9: Electrical Schematics

    ELECTRICAL SCHEMATICS Models 20 thru 75 - All Voltages Only Models 50 and 75 - 115-1-50/60 Only Models 50 and 75 - 230-1-50/60 LINE REFRIGERANT COMPRESSOR HIGH TEMPERATURE CONDENSER FAN MOTOR WIRING SCHEMATIC Models 100 and 125 - All Voltages LEGEND SW - On/Off Switch LINE...
  • Page 10: Dimensions And Weights

    DIMENSIONS AND WEIGHTS Models 20, 25, 35 257 mm 6 mm Model Weight 79 lbs (36 kg) 80 lbs (36 kg) 81 lbs (37 kg) 5.1/16 " 128 mm 718 mm 317 mm 1.9/16 " 1" 25 mm 40 mm 21 mm 5 mm 105 mm...
  • Page 11 DIMENSIONS AND WEIGHTS Models 50 and 75 425 mm Model Weight 6 mm 150 lbs (68 kg) 155 lbs (70 kg) 933 mm 8 7/16" 213 mm 419 mm 1.1/2" 25 mm 38 mm 15 1/4" 387 mm 21 mm 5 mm 117 mm 429 mm...
  • Page 12 DIMENSIONS AND WEIGHTS Models 100 and 125 Model Weight 187 lbs (85 kg) 189 lbs (86 kg) 1" 1"...
  • Page 13: Parts List

    PARTS LIST PARTS DESCRIPTION Separator *Separator/Filter Cartridge E9-16 E9-16 E9-16 E9-20 E9-24 Filter Sleeve S9-16 S9-16 S9-16 S9-20 S9-24 *Drain Mechanism 05.4170-08 05.4170-08 05.4170-08 05.4170-08 05.4170-08 Bowl 03.0810-04 03.0810-04 03.0810-04 03.0810-05 03.0810-06 *O-ring Bowl 9320.552.14 9320.552.14 9320.552.14 9320.552.16 9320.552.16 Inlet (Compressed Air) Strainer 4731.735.1 4731.735.1 4731.735.1...
  • Page 14 PARTS LIST PARTS DESCRIPTION Separator *Separator/Filter Cartridge E9-24 E9-24 Filter Sleeve S9-24 S9-24 *Drain Mechanism 05.4170-08 05.4170-08 Bowl 03.0810-06 03.0810-06 *O-ring Bowl 9320.552.16 9320.552.16 Strainer, inlet 4731.735.3 4731.735.3 *Screen, strainer 4731.735.8 4731.735.8 Electrical 6110.706.7 6110.706.7 Switch on/off Light, Fault 230v 6350.451.11 6350.451.11 Cord Set...
  • Page 15 NOTES...
  • Page 16: Warranty

    1415 California Avenue Canonsburg, PA 15317-1700 U.S.A. Brockville, ON , Canada , K6V 7H7 Phone: 724-745-8647 • Fax: 724-745-4967 Phone: 613-345-2280 • Fax: 613-345-7240 Email: deltech.inquiry@dehydration.spx.com Email: salescanada@dehydration.spx.com www.deltech-spx.com www.deltech-spx.com © 2006 SPX Dehydration & Process Filtration. All rights reserved.

This manual is also suitable for:

Htd 20Htd 25Htd 35Htd 50Htd 75Htd 100 ... Show all
