Models Hgen800A Through Hgen1200A - Deltech SPX FLOW Manual

MCGUIRE AIR COMPRESSORS INC
SPECIFICATIONS: AIR-COOLED UNITS
Air and Refrigerant Flow Schematic:

Models HGEN800A through HGEN1200A

TEMPERATURE
SENSOR
CAPILLARY
EXPANSION VALVE
TUBE
14
MCGUIRE AIR COMPRESSORS INC
MOISTURE SEPARATOR INTEGRATED
BRAZED PLATE HEAT EXCHANGER #2
(REF TO AIR) (AIR TO AIR)
MOISTURE SEPARATOR INTEGRATED
BRAZED PLATE HEAT EXCHANGER #1
(REF TO AIR) (AIR TO AIR)
TS
SCHRADER
VALVE
REFRIGERATION
COMPRESSOR
SCHRADER
VALVE
FILTER/DRYER
S
DRAIN VALVE ELECTRONIC AUTO
STRAINER DRAIN VALVE
S
DRAIN VALVE ELECTRONIC AUTO
STRAINER DRAIN VALVE
ALUMINUM CONDENSER #1
HIGH PRESSURE FAN PRESSURE
SWITCH SWITCH
ALUMINUM CONDENSER #2
H.P.S. F.P.S.
1-888-229-9999
WETTED COMPRESSED AIR INLET
DRYED COMPRESSED AIR OUTLET
AIR FLOW
FAN & FAN MOTOR
(AIR COOLED)
(AIR COOLED)
COMPRESSED AIR FLOW
REFRIGERANT FLOW
